SIEMENS 6ES7677-2SB42-0GM0 New and Original High quality

6ES7677-2SB42-0GM0

The 6ES7677-2SB42-0GM0 model product is a SIMATIC ET 200SP Open controller, belonging to the security software controller category. The core configuration includes a CPU 1515SP PC2F, 8GB RAM, and 128GB CFast storage. It comes pre installed with the Windows 10 IoT Enterprise LTSC 2019 64 bit operating system and S7-1500 fail safe software, and supports 2048 process variable licenses. Its hardware interface integrates 1 CFast slot, 1 SD/MMC slot, 1 ET 200SP PROFINET bus adapter interface, 1 Gigabit Ethernet port, 2 USB 3.0 interfaces, 2 USB 2.0 interfaces, and 1 display port, which can adapt to HMI 2048PT and other devices. As a modular component of the ET 200SP series, this controller achieves distributed expansion through the PROFINET protocol, is compatible with multiple bus adapters and field devices, supports fail safe communication and redundant configuration, and is suitable for scenarios in industrial automation that require high reliability, high real-time performance, and multi device integration, such as intelligent manufacturing production lines, process control systems, etc.

Technical specifcations for 6ES7677-2SB42-0GM0

hardware configuration

Processor and Memory:

Equipped with CPU 1515SP PC2F and 8GB RAM, it can meet the requirements of complex control tasks for computing speed and storage capacity.

Equipped with a 128GB CFast storage card and pre installed Windows 10 IoT Enterprise LTSC 2019 64 bit operating system, providing a stable environment for software operation.

Display and Interface:

Integrated HMI 2048PT display interface, supporting visual operation interface.

Configure 1 CFast slot and 1 SD/MMC slot to provide data storage expansion capability.

Equipped with one ET 200SP PROFINET bus adapter interface, supporting distributed I/O expansion.

Provide 1 Gigabit Ethernet port, 2 USB 3.0 ports, 2 USB 2.0 ports, and 1 display port to meet diverse peripheral connectivity needs.

2、 Software functions

Pre installed software: Integrated S7-1500 fault safety software, supporting integrated development of safety programs and standard programs.

License configuration: Contains 2048 process variable licenses, suitable for large-scale automation systems.

Programming support: Compatible with TIA Portal platform, supports calling of fault safety function blocks, and can achieve unified development of safety programs and standard programs.

3、 Environment and Safety

Protection level: IP20 protection level, suitable for cabinet installation environment.

Compliance certification: Complies with RoHS directive requirements to ensure compliance in the use of hazardous substances in electrical and electronic equipment.

Data Protection: Supports block password protection and copy protection functions to prevent unauthorized program access and copying.

4、 Physical characteristics

Size and weight: The product size is 14.40 × 18.90 × 9.50 centimeters, with a net weight of 1.041 kilograms.

Packaging specifications: Single piece packaging is used, with packaging dimensions of 14.40 × 18.90 × 9.50 centimeters.

Origin: Made in Germany, ensuring the quality of craftsmanship.
