SIEMENS 6ES7635-2EC00-0AE3 New and Original High quality

6ES7635-2EC00-0AE3

The 6ES7635-2EC00-0AE3 model product is a Siemens C7-635 series touch screen, which belongs to the field of industrial automation human-machine interaction equipment. It integrates LCD display and touch operation functions, supports connection with industrial control equipment such as Siemens PLC, and can realize data monitoring, parameter setting, and operation instruction input in industrial sites. This model adopts a modular design and is compatible with SIMATIC C7-635 overall equipment. It has a built-in S7-300 CPU 314C-2 DP and OP170B operation panel, with 24 digital inputs, 16 digital outputs, 5 analog inputs, and 2 analog output channels. It needs to be used in conjunction with a micro memory card (MMC) and connector. Its protection level meets the requirements of industrial environments and is widely used in mechanical manufacturing, process control, and automation production lines. It is suitable for industrial control systems that require intuitive operation interfaces and real-time data interaction.

Technical specifcations for 6ES7635-2EC00-0AE3

Hardware integration and interface:

Integrated components: Built in S7-300 CPU 314C-2 DP controller and OP170B operation panel, supporting 24 digital inputs (DI), 16 digital outputs (DO), 5 analog inputs (AI), and 2 analog outputs (AO), which need to be used in conjunction with a miniature memory card (MMC) and connector.

Interface configuration: Equipped with 2 USB interfaces, supporting data exchange and configuration of industrial equipment.

Electrical and protective parameters:

Working voltage: 24V DC, suitable for industrial control power supply systems.

Protection level: IP54, with dust-proof and splash proof capabilities, suitable for industrial environments.

Mechanical and installation characteristics:

Dimensions: 30.10cm × 33.30cm × 11.10cm, compact design saves space.

Net weight: 2.206kg, easy to handle and integrate.

Installation method: Supports 35mm DIN rail installation, suitable for industrial control cabinet layout.

Environmental adaptability:

Working temperature range: -10 ℃ to 70 ℃ (wide temperature type can choose -40 ℃ to+85 ℃), suitable for extreme environments.

Relative humidity: ≤ 90% (no condensation), to prevent moisture from causing malfunctions.

Storage temperature range: -40 ℃ to 80 ℃, ensuring long-term storage stability of the equipment.

Power and protection functions:

Power input: Supports dual power redundant input (DC 9-36V), typical value is 24V DC, power consumption<4W.

Isolation and protection: Equipped with DC 1500V voltage isolation and reverse protection functions, enhancing system reliability.

Alarm output: Fiber optic link failure and power failure alarm output, contact capacity DC 48V/1A.

Electromagnetic compatibility and certification:

Electromagnetic compatibility: Through standards such as EN55022:2010 (RE), EN61000-4-2:2001 (ESD), EN61000-4-3:2006 (RS), etc., it has strong anti-interference ability.

Environmental certification: Compliant with RoHS directive, restricting the use of hazardous substances.

Packaging and labeling: EAN code 4025515074625, originating from Germany, packaging size 30.10cm × 33.30cm × 11.10cm.
