SIEMENS 6ES7614-1AH02-0AB3 New and Original High quality

6ES7614-1AH02-0AB3

The 6ES7614-1AH02-0AB3 model product is a high-performance processor module (CPU module) in the Siemens SIMATIC series, designed specifically for industrial automation control and suitable for S7-400 series PLC systems. This module has strong computing power and high processing speed, supporting tasks such as complex logic control, process control, and motion control, and can meet the strict requirements of real-time and reliability for medium and large-scale automation projects; It adopts a compact design, compatible with standard S7-400 rack and backplane bus, supports multi processor collaboration, and can achieve seamless communication with distributed I/O, HMI, and other intelligent devices through PROFIBUS-DP or industrial Ethernet; The module is equipped with large capacity memory, supports multitasking operating systems, can flexibly expand functional modules (such as counters, positioning modules, etc.), and supports online debugging and fault diagnosis through STEP 7 programming software; In addition, the product meets industrial environmental standards, has electromagnetic compatibility and anti-interference capabilities, and is widely used in automated production lines in industries such as automotive manufacturing, chemical, energy, and mechanical processing, helping users improve production efficiency and reduce maintenance costs.

Technical specifcations for 6ES7614-1AH02-0AB3

Hardware and interface parameters

Processor performance: Adopting a high-performance 32-bit processor, the instruction execution speed can reach 0.08 μ s/instruction (typical value), which can quickly process complex logic and computational tasks.

Storage capacity:

Work memory: 2MB (expandable up to 8MB), used to store user programs and data.

Loading memory: 4MB (expandable to 64MB), used for storing system programs and configurations.

Interface configuration:

PROFIBUS-DP interface: Integrated with PROFIBUS-DP master/slave interface, supporting distributed I/O communication, with a maximum transmission rate of 12Mbps.

MPI/PROFINET interface: Supports MPI multi-point interface and PROFINET industrial Ethernet communication, enabling data exchange with other devices.

Optional Ethernet interface: Ethernet interface can be extended through communication processor modules such as CP443-1 to achieve high-speed network communication.

I/O expansion capability: up to 65536 points (digital+analog), meeting the control requirements of large-scale automation systems.

2、 Function and performance parameters

Processing speed: The instruction execution speed is fast, capable of processing large amounts of data in real-time, ensuring the efficient operation of the system.

Communication capability: Supports multiple communication protocols such as PROFIBUS-DP, MPI, PROFINET, etc., and can be seamlessly integrated with other Siemens devices or third-party devices.

Redundancy and Fault Tolerance: Supports redundant configuration, improves system reliability and availability, and is suitable for situations that require high continuous operation.

Diagnosis and maintenance: Built in diagnostic function, which can monitor module status in real time, provide fault alarms and diagnostic information, and facilitate quick positioning and problem-solving.

3、 Environmental and electrical parameters

Power requirement: 24V DC (typical value), power consumption of about 30W, suitable for power supply environment in industrial sites.

Work environment:

Temperature range: 0 ℃ to 60 ℃, suitable for a wide temperature range.

Humidity range: ≤ 95% (no condensation), ensuring stable operation in humid environments.

Protection level: Complies with industrial environmental standards, has electromagnetic compatibility and anti-interference ability, and can work stably in complex electromagnetic environments.

4、 Physical and packaging parameters

Size and weight: approximately 300mm x 200mm x 130mm, weighing around 3kg, easy to install and deploy.

Packaging content: Includes CPU module body, quick start guide, installation accessories, etc., providing a complete solution.

5、 Application scenarios

Automated control of large-scale production lines: For industries such as automobile manufacturing and food processing, achieve automated control and monitoring of production lines.

Process control system: suitable for process control in chemical, energy, water treatment and other fields, ensuring the stability and efficiency of the production process.

Intelligent infrastructure: such as building automation, traffic control, etc., to achieve intelligent management and control.
