6ES7416-3ER05-0AB0
The 6ES7416-3ER05-0AB0 model product is a high-performance central processing unit (CPU 416-3 PN/DP) for Siemens SIMATIC S7-400 series PLC, designed specifically for complex industrial automation scenarios. It has 11.2MB working memory (5.6MB program/5.6MB data) and PROFINET/PROFIBUS DP dual interfaces, supporting MPI, PROFINET I/O, CBA and other communication protocols. It can connect 256 IO devices, with instruction execution time as low as 0.03 microseconds, processing up to 262144 digital and 16384 analog input/output points. It integrates fault diagnosis buffer and real-time clock functions, adopts password protection and modular expansion design, and is suitable for automotive manufacturing, energy management, process industry and other fields, meeting the requirements. High precision control and distributed system integration requirements.
Technical specifcations for 6ES7416-3ER05-0AB0
Storage and Performance
Work memory: 11.2MB (5.6MB each for programs and data), used for fast execution of user programs.
Instruction execution time: Binary instructions can be as low as 0.03 microseconds, providing high-performance processing capabilities.
I/O capacity: Supports up to 262144 digital inputs and 16384 analog inputs/outputs, meeting large-scale automation requirements.
2、 Interface and Communication
Integrated interface:
MPI/PROFIBUS DP interface: supports a data transmission rate of 12 Mbit/s and can connect up to 32 stations.
PROFINET interface: 2-port switch design, supporting PROFINET I/O (up to 256 IO devices) and PROFINET CBA, to achieve distributed intelligent systems.
IF template slot: Supports plug-in interface template expansion.
Communication protocol: Supports PROFIBUS-DP master station (levels 1 and 2), PROFIBUS-DP slave station, S7 standard communication, open communication (based on FDL interface's SEND/RECIVE function), etc.
3、 Power supply and power consumption
Power supply voltage: rated value 24V DC, powered by system voltage.
Power consumption: Typical value is 6W, maximum value is 6.5W, meeting the low-power requirements of industrial equipment.
4、 Function and Safety
Clock synchronization: Supports PROFIBUS clock synchronization mode to ensure time consistency in distributed systems.
Fault diagnosis: Built in diagnostic buffer for 120 faults and interrupt events, supporting system self diagnosis.
Data Protection: The user program supports password protection to prevent unauthorized access.
Safety level: In fail safe applications, the safety level can reach SIL 3 (IEC 61508) and PL e (ISO 13849.1), supporting the integration of standard tasks and safety tasks.
5、 Expansion and Compatibility
Storage Expansion: Supports FEPROM and RAM storage card expansion, with a maximum capacity of 64MB.
Software compatibility: Supports STEP 7 V5.4 SP5 and above versions, and supports CiR synchronization time configuration.
Module compatibility: Compatible with digital input modules (such as DI16 × 24VDCBA 6ES7521-1BH10-0AA0).
6、 Environmental adaptability
Working temperature: -20 ° C to+60 ° C, meeting the diverse needs of industrial environments.
Protection level: IP20, suitable for indoor environments such as control cabinets.
