6ES7416-1XJ02-0AB0
The 6ES7416-1XJ02-0AB0 model product is a modular CPU module of the SIMATIC S7-400 series PLC, which adopts a modular structure and supports on-site installation. It is equipped with a hard PLC type LD instruction processor, built-in 24V DC working voltage interface, and has 24 point I/O signal processing capability (specific I/O points need to be combined with actual application configuration). It is suitable for logic control, process monitoring, and data acquisition tasks in industrial automation scenarios. This module relies on the Siemens S7-400 architecture and can seamlessly integrate with STEP 7 or TIA Portal programming tools. It supports expanding input/output points or adding functional modules through communication protocols such as PROFIBUS and PROFINET, and achieves high reliability control through a redundant network structure. Its compact design and standardized interfaces enable it to be flexibly embedded in industrial control systems, meeting complex process requirements in manufacturing, production lines, power systems, and other fields.
Technical specifcations for 6ES7416-1XJ02-0AB0
Structure and Installation:
Structural form: modular, convenient for on-site installation and system integration.
Installation method: Supports on-site installation and adapts to different industrial environment requirements.
Processor and Instructions:
LD instruction processor: using a hard PLC type instruction processor to ensure efficient and stable instruction execution.
I/O points and functions:
I/O points: Typically configured to 24 points (specific points may vary depending on application configuration), meeting general industrial automation control requirements.
Function: As the core control unit of PLC, responsible for logic control, data processing, and communication tasks.
Working voltage:
The official information does not explicitly mention the specific working voltage of this model, but the S7-400 series CPU module usually supports standard industrial voltage (such as 24V DC), which needs to be confirmed in conjunction with the actual product manual.
Storage and Performance:
Memory: The capacity of working memory and built-in loading memory should refer to the specific model parameters (such as 2.8MB program memory/2.8MB data memory for CPU 416-2), which may belong to the mid-range configuration.
Execution time: The execution time of bit operation instructions can reach nanoseconds (such as 75ns), ensuring high-speed data processing capability.
Communication interface:
Supports communication protocols such as MPI/DP and PROFIBUS, with expandable PROFINET interfaces (to be implemented through modules or configurations) to meet the complex communication requirements of industrial sites.
Software compatibility:
Support STEP 7 or TIA Portal programming tools for system development and maintenance.
Our Services:
1、All our products are new and orginal, and of good quality
2、Our prices are very competitive.
3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.
4、All inquiries will be valued and will reply in 24.
Packing & Delivery:
1、100% brand New and Original Factory Seal!
2、Warranty:1 year
3、Package: Original packing with cartons.
4、Delivery time: Shipped in 3-7 days after payment
5、All the goods will be tested before shipment
