6ES7392-1BJ00-1AB0
The 6ES7392-1BJ00-1AB0 model product is a front connector for Siemens S7-300 series PLC, which belongs to the signal module accessories of SIMATIC S7-300 system. It adopts a 20 pin spring contact design and achieves efficient electrical connection between the signal module and the backplane bus through a spring loaded connection method, ensuring mechanical installation reliability and electrical contact stability. Its modular structure supports plug and play, adapts to S7-300 series standard rail installation, is compatible with 24V DC power supply environment, and meets the strict requirements of signal transmission reliability and system scalability in industrial automation scenarios.
Technical specifcations for 6ES7392-1BJ00-1AB0
Basic information
Brand and Model: SIEMENS/Siemens, Model 6ES7392-1BJ00-1AB0.
Product type: Front connector, used for connecting signal modules of S7-300 series PLC.
Interface form: Equipped with 20 pin spring contacts, using a spring loaded connection method to ensure the reliability and stability of electrical contacts.
Applicable system: Specially designed for S7-300 series PLC, compatible with wiring requirements of S7-300 and ET 200M systems.
2、 Physical characteristics
Installation method: Suitable for DIN rail installation of S7-300 series PLC, supporting standardized deployment inside the control cabinet.
External dimensions: There are differences in display dimensions from different sources, with typical specifications being 18.70 × 42.90 × 14.60 centimeters or more compact 4.0 × 14.10 × 2.70 centimeters.
Weight: The common specifications are 5.198 kilograms or 0.059 kilograms, and the specific weight depends on the packaging form.
Packaging specifications: Supports single item retail or bulk supply of 100 pieces per packaging unit.
3、 Electrical parameters
Working voltage: Suitable for 24V DC power supply system, compliant with the power supply standards of S7-300 series PLC.
Protection level: With IP20 protection capability, it can resist the intrusion of solid particles and is suitable for installation environment inside control cabinets.
Environmental adaptability:
Working temperature: -30 ℃ to 60 ℃, covering extreme industrial environment requirements.
Environmental humidity: Some data shows support for 3% relative humidity, but the moisture resistance needs to be evaluated based on specific scenarios.
4、 Functional characteristics
Connection reliability: The spring contact design maintains electrical connection through mechanical pressure, effectively resisting vibration and impact effects.
Modular Expansion: Supports plug and play installation and can be quickly integrated into existing S7-300 system architectures.
Maintenance convenience: Standardized interface design simplifies the module replacement process and reduces downtime maintenance costs.
Signal integrity: By optimizing the contact material and structural design, the stability of high-speed signal transmission is ensured.
5、 Certification and Compliance
Product certification: Passed CE certification and meets EU safety and electromagnetic compatibility standards.
