SIEMENS 6ES7368-3BB00-0AA0 New and Original High quality

6ES7368-3BB00-0AA0

The 6ES7368-3BB00-0AA0 model product is a connection cable for SIMATIC S7-300 series PLC, specifically designed for communication connection between IM 360 and IM 361 interface modules in expansion rack systems. It adopts a standardized 1-meter length design, adapts to DIN rail installation, supports signal transmission of P-bus (IO bus) and K-bus (communication bus) between the host rack and expansion rack, and achieves industrial grade anti-interference performance through shielded twisted pair structure, ensuring stable transmission in a wide temperature environment of -25 ° C to+60 ° C and 30% relative humidity. As a key component of centralized expansion solutions, it can be used in conjunction with IM 360/361 interface modules to achieve multi rack expansion. Its 1-meter standard length is suitable for close range expansion scenarios. For longer distances, 2.5 meters (6ES7368-3BC51-0AA0), 5 meters (6ES7368-3BF01-0AA0), or 10 meters (6ES7368-3CB01-0AA0) can be selected Equivalent variant models to meet the flexible wiring needs of different industrial sites.

Technical specifcations for 6ES7368-3BB00-0AA0

Basic information

Brand and Model: SIEMENS, Model 6ES7368-3BB00-0AA0.

Product series: SIMATIC S7-300 series PLC interface module connection cable.

Purpose: Used to expand the communication connection between IM 360 and IM 361 interface modules in rack systems.

2、 Electrical and mechanical parameters

Working voltage: 24V DC, compatible with the power requirements of S7-300 series PLC.

Interface type: Adopting standardized interface design, compatible with DIN rail installation method, easy to integrate into S7-300 system.

Protection level: IP20, meeting the basic protection requirements of industrial sites and effectively preventing solid foreign objects from entering.

Length: The standard length is 1 meter, suitable for close range expansion scenarios.

Weight: Approximately 0.225kg (specific weight may vary slightly depending on product batch).

3、 Communication and transmission characteristics

Bus type: Supports PROFIBUS DP communication protocol to achieve signal transmission between the host rack and the expansion rack via P bus (IO bus) and K bus (communication bus).

Transmission performance: By shielding the twisted pair structure, industrial grade anti-interference performance is achieved to ensure the stability and reliability of data transmission.

Signal transmission: Supports efficient signal transmission between S7-300 controllers and field devices, meeting the needs of complex automation operations.

4、 Environmental adaptability

Working temperature range: -25 ° C to+60 ° C, suitable for different industrial environment temperatures.

Storage temperature range: -40 ° C to+85 ° C, ensuring stable module performance under extreme conditions.

Relative humidity: 30% (can still operate reliably in specific humidity environments).

5、 Scalability and compatibility

Scalability: As a key component of centralized expansion solutions, it can be combined with IM 360/361 interface modules to achieve multi rack expansion.

Compatibility: Compatible with other modules of S7-300 series PLC, such as CPU, signal module, communication processor, etc., supporting flexible system configuration.

Variant models: Provide different length variants (such as 2.5 meters, 5 meters, 10 meters, etc.) to meet the wiring needs of different industrial sites.

6、 Certification and Quality

Product certification: Ensure product quality and safety through relevant industrial standard certification (such as 3C certification).

Quality standards: Adhere to strict quality control processes to ensure the stability and reliability of modules in various industrial environments.
