SIEMENS 6ES7314-1AG14-0AB0 New and Original High quality

6ES7314-1AG14-0AB0

The 6ES7314-1AG14-0AB0 model product is a CPU 314 central processing unit module for Siemens S7-300 series PLC, integrating 24V DC power supply and 128KB working memory. It adopts a 32-bit RISC processor architecture to achieve efficient data processing and supports the construction of distributed communication networks through MPI, PROFIBUS, and industrial Ethernet. It is equipped with micro storage card slots to expand the loading storage capacity and has modular design, industrial grade anti-interference ability, and online upgrade function. It can seamlessly integrate with S7-300 series I/O modules and functional modules, and is suitable for manufacturing, energy, building automation and other fields. It meets the industrial control needs of small and medium-sized control systems for short cycle time, fast processing speed, and flexible system expansion.

Technical specifcations for 6ES7314-1AG14-0AB0

Basic information

Product positioning: SIMATIC S7-300 series, CPU 314 model, integrated 24V DC power supply central processor module, suitable for small and medium-sized control systems.

Memory: Equipped with 128KB working memory, supporting the expansion of loading storage capacity through micro memory cards (MMC), with a maximum expandable capacity of 8MB, to meet the storage needs of complex programs.

2、 Electrical parameters

Power specification: Rated voltage 24V DC, allowable input range 19.2V to 28.8V, with overvoltage and undervoltage protection functions to ensure power supply stability.

Power consumption: rated current of 650mA, no-load current of 140mA, typical turn-on current of 3.5A, power loss of about 4W, suitable for low-power industrial scenarios.

3、 Processing performance

Calculation speed: Typical value of bit operation is 0.06 µ s, word operation is 0.12 µ s, fixed-point operation is 0.16 µ s, floating-point operation is 0.59 µ s, supporting fast processing of complex logic.

Instruction set: Contains over 350 instructions, covering functions such as bit manipulation, arithmetic operations, data conversion, etc., compatible with the STEP 7 programming environment.

4、 Communication interface

Integrated interface: Supports MPI multi-point interface (transmission rate 187.5kbit/s), optional PROFIBUS-DP or industrial Ethernet module, to achieve distributed control.

Protocol support: Compatible with PROFIsafe security protocol, supports PG/OP communication, routing, and global data communication, meeting the communication requirements of Industry 4.0.

5、 Expansion capability

Module Expansion: Supports up to 32 expansion modules, with integrated backplane bus within the module, and flexible configuration achieved through the "HWConfig" tool.

Hardware compatibility: Compatible with S7-300 series I/O modules, functional modules, and communication processors, supporting distributed I/O synchronous signal processing.

6、 Environmental adaptability

Protection level: Complies with IP20 standard, adapts to non-conductive dust environment, and has excellent resistance to vibration and impact.

Temperature range: working temperature -20 ℃ to 60 ℃, with an upper limit of 50 ℃ when installed vertically, and can withstand extreme temperatures of -25 ℃ to 70 ℃ in the short term.

7、 Functional characteristics

Real time clock: Built in hardware clock (RTC), supports buffering and synchronization functions, can still run for 6 weeks after power failure, ensuring accurate time recording.

Diagnostic function: Provides interrupt organization block (OB) support, including startup OB, asynchronous error OB, etc., supporting rapid fault location and handling.

Data Management: MMC supports persistent storage of data, with a minimum data management unit of 10 years to ensure that critical parameters are not lost.

8、 Software support

Programming tool: Compatible with STEP 7 V5.5 SP2 and above versions, supporting ladder diagram (LAD), function block diagram (FBD), and statement table (STL) programming.

System compatibility: Seamless integration with TIA Portal platform, supporting the concept of fully integrated automation (TIA), simplifying the engineering configuration process.
