SIEMENS 6ES7313-6CE00-0AB0 New and Original High quality

6ES7313-6CE00-0AB0

The 6ES7313-6CE00-0AB0 model product is a compact CPU module in the Siemens S7-300 series PLC. It belongs to a modular structure design and supports the expansion of digital/analog input/output modules, communication processors, and functional modules through a backplane bus, adapting to the distributed control architecture requirements in the industrial automation field; This module has a 128KB working memory, supports bit operation processing time as low as 0.1 μ s, and integrates PROFIBUS DP interface and MPI multi-point interface, which can achieve high-speed connection between fieldbus communication and programming devices; Its hardware configuration includes 128 digital input/output channels, supporting floating-point operations and PID control functions. Combined with STEP 7 programming tools, it can complete complex logic control and motion control tasks; The product has passed CE certification, with a working temperature range of -20 ℃ to+60 ℃ and a protection level of IP20. It is suitable for building small and medium-sized automation systems in mechanical manufacturing, process control, and other scenarios.

Technical specifcations for 6ES7313-6CE00-0AB0

Product positioning and hardware:

Model: 6ES7313-6CE00-0AB0, belonging to the S7-300 series CPU 313C-2 DP compact module.

Memory: The working memory has a capacity of 32KB and can be expanded for program storage through a micro memory card (MMC), with a maximum support of 8MB.

Installation method: Modular design, supporting DIN rail installation, compatible with S7-300 series standard racks.

Input/output interface:

Digital input: Integrated 16 channel digital input, supporting 24V DC signal input.

Digital output: Integrated 16 channel digital output, supporting 24V DC signal output.

Interface type: Both input and output channels have reverse polarity protection function, enhancing on-site signal adaptation capability.

Communication function:

Integrated interface: equipped with PROFIBUS DP master/slave interface, supporting distributed I/O system connection.

MPI interface: Built in multipoint interface (MPI), which can communicate with programming devices, HMI, or other PLCs.

Communication speed: The PROFIBUS DP interface supports a maximum communication speed of 12Mbps, while the MPI interface supports a communication speed of 187.5Kbps.

Technical performance:

Processing speed: The shortest bit operation processing time is 0.1 μ s, the shortest word operation processing time is 0.2 μ s, and the shortest floating-point operation processing time is 3 μ s.

Instruction set: Supports a powerful instruction set containing over 350 instructions, enabling complex logic control and computation functions.

Counting function: Integrated with 3 30kHz high-speed counters, supporting independent directional comparison and incremental encoder connection.

Power supply and power consumption:

Power supply voltage: Supports 24V DC power input, allowing a voltage range of 20.4V to 28.8V.

Power consumption: Typical power consumption is 10W, no-load power consumption is 100mA, and peak on current is 11A.

Environment and Protection:

Working temperature: wide temperature range from -20 ℃ to+60 ℃, suitable for complex industrial environments.

Protection level: IP20 protection level, suitable for indoor environments without conductive dust.

Electromagnetic compatibility: Compliant with EMC compatibility design, with excellent resistance to vibration and impact.

Scalability:

Module Expansion: Supports the expansion of digital/analog input/output modules, communication processors, and functional modules through the backplane bus.

Distributed I/O: Can connect ET 200M distributed I/O system to achieve distributed control architecture.

Programming and Debugging:

Programming software: Supports STEP 7 V5.5 SP2 and above programming software, providing programming languages such as ladder diagrams, statement tables, and functional block diagrams.

Debugging function: supports online debugging, diagnostic buffer viewing, forced modification of process variables, and other functions.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
