SIEMENS 6ES7223-1PL30-0XB0 New and Original High quality

6ES7223-1PL30-0XB0

The 6ES7223-1PL30-0XB0 model product is a digital input/output module for Siemens SIMATIC S7-1200 series PLC, with 16 digital input and 16 relay output functions, supporting 24V DC input signal acquisition and relay contact load control. It adopts modular design and can be directly integrated with S7-1200 CPU, achieving high-speed data exchange through PROFINET interface. Its input/output channel electrical isolation design effectively suppresses industrial field interference, and its wide temperature operation ability from -25 ℃ to+70 ℃ is suitable for complex working conditions such as metallurgy and water treatment. It is matched with TIA Portal engineering software to complete module parameter configuration and fault diagnosis, especially suitable for automation control scenarios that require low to medium load switch signal processing.

Technical specifcations for 6ES7223-1PL30-0XB0

Basic information

Brand and Model: Siemens, Model 6ES7223-1PL30-0XB0.

Product positioning: Digital input/output module for S7-1200 series PLC, used in industrial automation control scenarios, supporting switch signal processing for medium and low loads.

2、 Electrical parameters

Working voltage: Typically 24V DC, the allowable range may be between 20.4V and 28.8V DC (please refer to the product manual for details).

Input characteristics:

Number of input channels: It may be 16 channels (please refer to the product manual for specific quantities).

Input type: Supports 24V DC input signal acquisition.

Input current: There are clear current range requirements for signals "0" and "1" to ensure stable signal recognition.

Output characteristics:

Number of output channels: possibly 16 channels (specific quantity to refer to product manual).

Output type: Relay output, suitable for switch control of medium and low loads.

Load capacity: The maximum output current and load voltage range for each channel should refer to the specific product manual (similar models such as 6ES7223-1PL32-0XB0) 2A@230V  AC/30V DC）。

3、 Interface and Communication

Interface type: Supports data exchange with S7-1200 series PLC through backplane bus.

Communication protocol: Compliant with PROFINET or PROFIBUS communication standards (specific to product manual).

4、 Environmental adaptability

Working temperature range: usually supports -25 ℃ to+70 ℃ (specific to product manual), suitable for complex industrial environments.

Protection level: IP20, suitable for installation inside industrial control cabinets.

5、 Mechanical and Installation

Installation method: Supports DIN rail installation for easy fixation inside the control cabinet.

Module size: The specific size needs to refer to the product manual, but it is usually designed to be compact to save space.

6、 Functional characteristics

Input/output isolation: Electrical isolation between digital input and output channels effectively suppresses interference.

Diagnostic function: Supports module status diagnosis for easy maintenance and troubleshooting.

Parameter configuration: Parameter configuration and fault diagnosis can be performed through TIA Portal engineering software.

7、 Application Fields

Industrial automation: suitable for applications such as mechanical manufacturing, water treatment, and logistics transportation that require low to medium load switch signal processing.
