SIEMENS 6ES7212-1BE31-0XB0 New and Original High quality

6ES7212-1BE31-0XB0

The 6ES712-1BE31-0XB0 model product is a digital module for the Siemens S7-1200 series PLC. It adopts a DC/DC/relay power configuration, integrates 8 digital inputs (DI) and 6 digital outputs (DO), and is equipped with 2 analog inputs (AI). It supports communication with the main control system through Ethernet ports. The module is non expandable and suitable for standard automation control scenarios. Its compact design can be installed horizontally or vertically on DIN rails, and independent wiring can be achieved through an integrated junction box to meet the basic I/O signal processing needs of industrial sites.

Technical specifcations for 6ES7212-1BE31-0XB0

Power and I/O configuration:

Power supply type: DC/DC/relay, which means the power supply is DC 24V, the input is DC 24V, and the output is relay type.

Digital input: 8 channels, 24V DC.

Digital output: 6 channels, relay output.

Analog input: 2 channels, supporting 0-10V DC signals.

Memory:

Working memory: Integrated 50KB of working memory for user programs and user data.

Loading memory: Integrated 1MB loading memory for storing programs.

Memory card support: Supports SIMATIC memory cards, expandable up to 24MB, used for program transfer or firmware updates.

Communication interface:

Integrated interface: equipped with PROFINET interface, supporting programming, HMI connection, and PLC to PLC communication.

Data transmission rate: Supports 10/100 Mbit/s to meet high-speed communication requirements.

Protocol support: Compatible with TCP/IP native, ISO on TCP, and S7 communication protocols.

Scalability:

Signal module expansion: Can connect 2 signal modules to expand digital or analog I/O capacity.

Signal board expansion: Supports adding 1 signal board, customizable digital or analog I/O, without affecting controller size.

Physical characteristics:

Installation method: Supports horizontal or vertical installation on DIN rails, suitable for different installation environments.

Protection level: IP20, suitable for non explosion proof areas.

Size and weight: Width of approximately 90mm, weight of approximately 0.34kg, compact structure.

Environmental adaptability:

Working temperature: 0 ° C to 55 ° C, suitable for various industrial environments.

Storage temperature: -25 ° C to 70 ° C, ensuring the stability of the device under extreme conditions.

Relative humidity: 5% to 95% (no condensation), suitable for high humidity environments.

Input characteristics:

Input voltage: 24V DC, supports logic 1 signal (15-30V DC) and logic 0 signal (0-5V DC).

Input delay: Supports filtering input and interrupt input delay from 0.2ms to 12.8ms, user configurable.

Input current: minimum 2.5mA for logic 1 signal, maximum 1mA for logic 0 signal.

Output characteristics:

Output type: Relay output, supports dry contacts.

Output voltage range: 5V DC to 30V DC (DC) or 5V AC to 250V AC (AC).

Output current: The maximum current for logic 1 signal is 2A, and the maximum current for each group is 6A.

Mechanical lifespan: 1 million on/off cycles without load, 100000 on/off cycles with nominal load.

Function and Features:

High speed counter: Integrated 4-axis 100kHz pulse output (transistor type), supporting open-loop control of stepper motors and servo drivers.

PID control: Supports up to 16 PID control loops, suitable for simple process control.

Motion control: Supports axis technology objects and PLCopen motion function blocks to achieve absolute movement, relative movement, and speed movement.

Programming software: Supports TIA Portal or STEP 7 Basic, providing an intuitive and easy to learn programming environment.
