SIEMENS 6ES7212-0AA50-0AA0 New and Original High quality

6ES7212-0AA50-0AA0

The 6ES712-0AA50-0AA0 model product is a compact CPU module for Siemens S7-200 SMART series PLC, designed specifically for small automation control systems. It integrates Ethernet interface, RS485 serial port, and Micro SD card slot, supports high-speed counting, real-time clock, and pulse output functions, and can flexibly expand the signal board to increase digital/analog I/O or communication interfaces. Its modular design combined with compact structure can efficiently adapt to the space limitations and functional requirements of industrial sites, suitable for application scenarios that require moderate logic control complexity and balance scalability and communication capabilities, such as equipment single machine control, simple production line automation, etc. It can be easily programmed and debugged through STEP 7-Micro/WIN SMART software.

Technical specifcations for 6ES7212-0AA50-0AA0

Electrical parameters

Input voltage: Supports 24V DC power supply, with a typical input range of 20.4V DC to 28.8V DC.

Output type: Supports transistor output (ST series) and relay output (SR series). The transistor output type supports high-speed pulse output, while the relay output type does not.

Digital input/output: This machine integrates digital input 12 input/8 output (SR20), 18 input/12 output (ST20) and other configurations, depending on the model.

Analog input/output: It needs to be implemented through an expansion module, such as EM AQ02 supporting 2-channel analog output (± 10V or 0-20mA), with a resolution of 12 bits (voltage)/11 bits (current).

2、 Performance parameters

Boolean execution speed: 0.15 μ s/instruction, Move Word execution speed 1.2 μ s/instruction, Real Math execution speed 3.6 μ s/instruction.

High speed counter: Supports 6-channel high-speed counters, with a maximum frequency of 200kHz for single-phase and 100kHz for phase A/B.

High speed pulse output: The transistor output type supports up to 100kHz pulse output and is suitable for stepper motors or servo control.

Communication interface: Integrated with one Ethernet port (10/100Mb/s) and one RS485 interface (PPI protocol speed 9600-187500b/s, free port communication speed 1200-115200b/s).

Storage Capacity: User Storage Area Program Storage Area 12K bytes to 30K bytes, Data Storage Area 8K bytes to 20K bytes, Keep Storage Area 10K bytes.

3、 Environmental parameters

Working temperature: 0 ° C to 55 ° C (horizontal installation), 0 ° C to 45 ° C (vertical installation).

Relative humidity: 95%, no condensation.

Atmospheric pressure: 1080 to 795hPa (equivalent to an altitude of -1000 to 2000m).

Protection level: Meets industrial grade protection standards and is suitable for harsh environments.

4、 Scalability and Functionality

Signal board expansion: Supports signal board expansion, such as SB DT04 providing a 4-point input/output mixed signal board, and SB AQ01 providing a 1-channel analog input/output signal board.

Expansion module: Supports up to 6 expansion modules (including signal board), such as EM DE08 for 8-point digital input module and EM DT08 for 8-point digital output module.

Real time clock: accuracy ± 120 seconds/month, maintained by supercapacitors for 7 days (typical value, 25 ° C).

Power supply capacity: maximum 1400mA (5V DC), sensor power supply maximum 300mA (24V DC).

5、 Physical parameters

Dimensions: Depending on the model, the dimensions range from 90mm × 100mm × 81mm to 175mm × 100mm × 81mm.

Installation method: Supports DIN rail installation for easy on-site deployment.
