6ES7195-3BF03-0YA0
The 6ES7195-3BF03-0YA0 model product is a Siemens PROFIsafe Starter V3.5 development kit, designed based on the PROFIsafe security protocol (V2.6.1 version) and integrated with the ERTEC 200P industrial Ethernet communication chip, which can achieve functional safety communication in PROFINET networks. This kit includes a hardware development board (EB 200P evaluation board), testing application software, and technical documentation. It supports the development and verification of the PROFIsafe protocol and is suitable for automation systems that require integrated safety communication functions, such as industrial robots, production line safety protection, etc. It can achieve reliable transmission of safety related data (such as emergency stop signals, safety door status) through a standard PROFINET network and comply with the Functional Safety Integrity Level (SIL) certification requirements, helping users quickly build industrial safety solutions that comply with the IEC 61508 standard.
Technical specifcations for 6ES7195-3BF03-0YA0
Hardware and interface parameters
Communication chip: Integrated with ERTEC 200P industrial Ethernet controller, supporting PROFINET real-time communication protocol, realizing parallel transmission of standard data and secure data.
Interface configuration:
PROFIsafe interface: compatible with PROFIsafe V2.6.1 configuration files, supports redundant transmission of safety related data (such as emergency stop signals, safety door status), and uses CRC-32 algorithm for data integrity verification.
PROFINET interface: Supports 100Mbps full duplex communication, RT (real-time) and IRT (synchronous real-time) communication modes, suitable for high-precision scenarios such as motion control.
Hardware compatibility: It needs to be used in conjunction with the EB 200P evaluation board and supports accessing the GPIO interface of the ERTEC 200P chip through pin headers for hardware expansion and signal debugging.
2、 Functional safety parameters
Safety certification: Passed T Ü V certification in Germany (certificate number 109738698), compliant with international functional safety standards such as IEC 61508 SIL 3, IEC 62061 PL e, ISO 13849-1 Cat.4, etc.
Secure communication capability:
Security protocol stack: Integrated PROFIsafe driver software (PSD), supports multi instance functionality, and can configure up to 16 secure channels per device.
Secure data length: Supports variable process data length (1-244 bytes) to meet different security control requirements.
Response time: The safe communication cycle time is ≤ 10ms, ensuring the reliability of rapid response scenarios such as emergency stop.
Fault diagnosis: Built in mechanisms such as CRC verification, serial number verification, and timeout monitoring support real-time diagnosis and localization of safety related faults.
3、 Development support parameters
Development resources:
Source code and documentation: Provides PSD source files, English/German comprehensive implementation manuals, CRC calculation tools, and programming examples, covering the complete development process from initialization to secure communication.
Toolchain: Supports TIA Portal V17 and above versions, compatible with STEP 7 Basic/Professional software, and provides GSDML files and device description files (DD).
Example program: Includes typical application examples such as safety emergency stop, safety door monitoring, safety speed monitoring, etc., supporting direct compilation and debugging.
Debugging tool: Integrated PROFIsafe monitoring tool, which can display real-time safety communication status, error counters, and diagnostic buffer information.
4、 Environmental and certification parameters
Protection level: IP20 protection level, suitable for installation inside control cabinets.
Environmental adaptability:
Working temperature: -25 ° C to+60 ° C, storage temperature: -40 ° C to+85 ° C.
Humidity range: 5% to 95% (no condensation).
Anti interference capability: Complies with EN 61000-6-2 (Electromagnetic Compatibility in Industrial Environments) standard.
Compliance certification:
Electrical safety: Complies with IEC 60950-1 standard.
Environmental requirements: Meet RoHS directive, lead content<0.1% (w/w),
Export control: ECCN code is EAR99S, with no special export restrictions.
5、 Physical and packaging parameters
Size and weight: The packaging size is 195mm × 239mm × 24mm, with a net weight of 0.183kg, which is convenient for laboratory and on-site deployment.
Packaging content: Includes the main body of the development kit, a quick start guide, a USB driver CD, and a copy of the T Ü V certification certificate.
Warranty period: 1 year warranty from the date of shipment, supported by technical support from Siemens Global Service Network.
6、 Application scenarios
Typical industries: mechanical manufacturing (such as robot welding lines), automotive production (such as press safety protection), chemical industry (such as emergency pressure relief for reaction vessels), food and beverage (such as safety door monitoring for filling lines).
Network topology: Supports linear, star, and redundant ring network structures, with a maximum of 8 PROFIsafe slaves connected to a single kit, and supports secure communication across network segments.
