6ES7194-2LN10-0AB0
The 6ES7194-2LN10-0AB0 model product is an M8 bus cable for Siemens ET200 series PLC, which belongs to the flexible plug-in cable type and is designed specifically for distributed I/O systems. It is suitable for connecting ET200 interface modules (such as ET200AL) to expand the connection capabilities of field devices. The cable adopts a 4-core shielding structure, with M8 plugs pre installed on both sides, providing various length specifications from 0.19m to 15m, supporting IP65/67 protection level, suitable for wide temperature environments from -30 ℃ to+80 ℃ and harsh industrial scenarios. Its shielding layer is composed of aluminum adhesive foil and tinned copper wire braided layer, with a bending cycle life of 1 million traction chain cycles (bending radius of 100mm, speed of 4m/s, acceleration of 4m/s ²), meeting the requirements of dynamic applications. The outer sheath of the cable is made of PVC material with green markings. The insulation color of the data cable core is white/yellow/blue/orange, with a unit length weight of 34kg/km. It is compatible with industrial communication protocols such as Siemens PROFINET/PROFIBUS and is suitable for automation fields such as automotive manufacturing, metallurgy, and water treatment.
Technical specifcations for 6ES7194-2LN10-0AB0
Product type: M8 bus cable belonging to Siemens ET200 series PLC, which is a flexible plug-in cable.
Origin: Germany.
Hardware parameters:
Interface form: Two M8 plugs are used on each side of the cable for assembly, with a total of 4 pins and shielded.
Cable structure:
Shielding layer: A shielding braided layer made of overlapping aluminum foil wrapped with tin plated copper wire.
wireway:
Wire name: 2Y (ST) CY 1x4x0.5/1.0-100-GN.
Outer diameter of inner conductor: 0.5mm.
Core wire insulation outer diameter: 1mm.
Outer diameter of cable sheath: 5mm.
Core wire insulation color: white/yellow/blue/orange.
Cable sheath material: PVC.
Cable sheath color: green.
Unit length weight: 34kg/km.
Performance parameters:
Bending performance:
The minimum allowable one-time bending radius is 20mm.
Minimum allowable multiple bending radius: 40mm.
Bending radius during continuous bending: 100mm.
Bending cycle times: When the bending radius is 100mm, the speed is 4m/s, and the acceleration is 4m/s ², the bending cycle of the traction chain is 1 million times.
Environmental adaptability:
Protection level: IP65/67, in compliance with EN 60529 standard.
The ambient temperature range during installation is -30 ° C to 80 ° C.
Environmental temperature range during transportation/storage: -40 ° C to 80 ° C.
Application and compatibility:
Applicable system: Connected to ET-CONNECTION nodes (such as SIMATIC ET 200AL), used for expanding distributed I/O systems.
Communication protocol: adapted to industrial communication protocols such as PROFINET/PROFIBUS.
