SIEMENS 6ES7157-1AA00-0AB0 New and Original High quality

6ES7157-1AA00-0AB0

The 6ES7157-1AA00-0AB0 model product is the PROFIBUS interface module IM 157-1 DP in the Siemens SIMATIC ET 200AL series, which has an IP67 protection level and can adapt to harsh industrial environments. It achieves high-speed communication with the main station system through the PROFIBUS DP protocol. The module integrates STEP 7 configuration function and supports GSD file configuration, which can stably connect on-site I/O devices. It is suitable for automation production lines, process control systems, outdoor equipment and other scenarios that require distributed control architecture. With its compact design and industrial grade reliability, it has become a key component for achieving decentralized I/O data exchange.

Technical specifcations for 6ES7157-1AA00-0AB0

Basic identification and protection level:

Product Name: SIMATIC ET 200AL PROFIBUS Interface Module IM 157-1 DP.

Protection level: IP67, with high protection performance, suitable for harsh industrial environments.

Electrical parameters:

Working voltage: 24V DC, in line with common power supply standards in industrial sites.

Load voltage: 1L+rated value 24V DC, allowable range from 20.4V DC to 28.8V DC, and equipped with reverse polarity protection function to prevent module damage caused by voltage connection.

Input current and power loss: The rated current consumption is 50mA (from a load voltage of 1L+), and the typical power loss is 1.7W, ensuring that the module operates efficiently while reducing energy consumption.

Communication and Interface:

Number of interfaces: Equipped with one PROFIBUS interface, supporting fieldbus communication.

Physical interface: Using M12 ports to provide reliable electrical connections.

Protocol support: Supports PROFIBUS DP protocol, with a data transmission rate range of 9.6kbit/s to 12Mbit/s, meeting different industrial communication needs.

Address range: The maximum address space for each site is 244 bytes, which can meet the needs of medium-sized data transmission.

Configuration and Control:

Configuration tool: Supports STEP 7 TIA Portal (since version V13 SP1 or above) and STEP 7 (since version V5.5 SP4 Hotfix 3 or above) for configuration, making it convenient for users to configure the system.

GSD file version: Supports GSD revision 5 or above, ensuring compatibility with mainstream PROFIBUS master stations.

Configuration method: Configure through data groups, supporting flexible system integration.

Diagnosis and Display:

Diagnostic function: It has diagnostic alarm function and can monitor the real-time operation status of the module.

LED indicator lights: Provide LED indicator lights such as RUN, ERROR, MAINT, LINK TX/RX, etc., which visually display the module's operating status, error information, maintenance requirements, and communication connection status through different colors (such as green, red, yellow).

Electrical isolation and safety:

Potential isolation: Implement potential isolation between load voltages and between PROFINET and all other circuits to improve the system's anti-interference ability and safety.

Safety standards: comply with relevant safety standards (such as FS01 and above versions) to ensure the safety and reliability of the module in industrial applications.

Environmental adaptability:

Working temperature range: -25 ° C to 55 ° C, can adapt to a wide range of temperature changes.

Connection technology: The power supply voltage electrical connection adopts M8 4-pole connector, with shielding design to enhance anti-interference ability.

Mechanical parameters:

Dimensions: Width 45mm, height 159mm, depth 40mm, compact design saves installation space.

Weight: Approximately 263g, easy to install and transport.

Installation method: Supports DIN rail installation and complies with industrial site installation standards.

Certification and Compliance:

Product certification: Passed ROHS certification and meets environmental requirements.
