SIEMENS 6ES7154-8AB00-0AB0 New and Original High quality

6ES7154-8AB00-0AB0

The 6ES7154-8AB00-0AB0 model product is an interface module (IM 154-8 PN/DP CPU) in the Siemens SIMATIC ET 200pro series, designed specifically for distributed I/O systems. It integrates PROFINET and PROFIBUS DP dual interfaces, supports master/slave mode communication, has 384KB working memory, and can be adapted to micro memory cards (MMC) for program and data storage. Its IP65/67 protection level and compact modular structure enable it to be directly deployed in industrial sites without the need for control cabinet protection. It is suitable for harsh environments such as high dust and humidity. By integrating clock synchronization and real-time diagnostic functions, it can be seamlessly integrated with STEP 7 engineering systems, meeting the requirements of modular design in discrete manufacturing and process control fields. Strict requirements for high protection and real-time communication.

Technical specifcations for 6ES7154-8AB00-0AB0

Core functions and interfaces

Communication interface: Integrated PROFINET interface and PROFIBUS DP master/slave interface, supports dual protocol communication, and can flexibly adapt to different industrial network architectures.

Storage capacity: Equipped with 384KB working memory and supporting micro memory card (MMC) expansion loading memory, with a maximum capacity of 8MB, meeting the storage needs of complex programs and data.

Protection level: up to IP65/67 standard, with dustproof, waterproof, and anti vibration capabilities, can be directly deployed in harsh industrial environments.

2、 Electrical characteristics

Power parameters: The rated working voltage is 24V DC, allowing input range of 20.4V to 28.8V, with reverse polarity protection function, suitable for voltage fluctuation scenarios.

Power consumption control: Typical power consumption of 8.5W, supports low-power operation, reduces system energy consumption and heat dissipation requirements.

Current characteristics: Typical current consumption is 350mA, no-load current is 250mA, and turn-on current is 2A to ensure the stability of equipment startup and operation.

3、 Performance parameters

Processing speed: Typical processing time for bit operations is 0.05 µ s, word operations is 0.09 µ s, fixed-point operations are 0.12 µ s, floating-point operations are 0.45 µ s, and high-speed real-time control is supported.

Clock synchronization: Built in hardware clock (real-time clock), supports buffering and synchronization functions, with a buffering duration of 6 weeks (40 ℃ environment), ensuring time consistency in distributed systems.

Diagnostic function: Provides three-level diagnostic information, supports rapid fault location and warning, and improves system maintenance efficiency.

4、 Environmental adaptability

Temperature range: Operating temperature -20 ℃ to+60 ℃, storage temperature -40 ℃ to+85 ℃, suitable for extreme industrial environments.

Protection design: IP65/67 protection level, can resist environmental interference such as dust, moisture, mechanical impact, etc., ensuring long-term stable operation.

5、 Software and Compatibility

Engineering System: Compatible with STEP 7 V5.5 and above versions, supports Distributed Safety V5.4 SP4 and other safety feature packages, simplifies system configuration and programming.

Expansion compatibility: It can be extended to ET 200pro distributed I/O systems, seamlessly integrated with PLCs such as S7-1500, and supports modular design.

Protocol support: Through PROFINET and PROFIBUS DP interfaces, interconnection and intercommunication with industrial Ethernet and fieldbus devices can be achieved.

6、 Mechanical Structure and Installation

Compact design: Modular structure, supports direct installation on industrial sites, no need for control cabinet protection, saves space and costs.

Installation method: Suitable for 19 inch control cabinets or consoles, supporting standard DIN rail installation for easy on-site deployment and maintenance.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
