SIEMENS 6ES7148-6JD00-0AB0 New and Original High quality

6ES7148-6JD00-0AB0

The 6ES7148-6JD00-0AB0 model product is an IO Link master station module in the Siemens ET200eco PN system, with 4 IO Link ports (supporting 4xM12 interfaces) and a protection level of IP67, suitable for complex industrial environments. This module integrates PROFINET interface and supports IO Link 1.0/1.1 protocol, with transmission rates ranging from 4.8kBaud to 230kBaud. The maximum output current of a single port is 500mA and it has short-circuit protection function. It can be connected to IO Link devices such as encoders simultaneously, achieving efficient transmission of digital input/output and sensor data, meeting the integration requirements of distributed I/O and intelligent sensors in industrial automation.

Technical specifcations for 6ES7148-6JD00-0AB0

Product type and identification:

Type: SIMATIC DP, ET 200eco PN, IO Link Master Station

Identification: 6ES7148-6JD00-0AB0

Interface and Connection:

Number of ports: 4 IO Link ports

Interface type: 4xM12

Protection level: IP67, suitable for industrial site environment

Electrical parameters:

Rated voltage (DC): 24V

Input current: The typical current consumption from the power supply voltage 1L+is 100mA, and the maximum current from the load voltage 2L+is 4A

Encoder power supply: maximum output current of 500mA per channel, with short-circuit protection

Power loss: Typical value is 4.8W

IO Link features:

Supported protocols: IO Link 1.0 and IO Link 1.1

Transmission rates: 4.8kBaud (COM1), 38.4kBaud (COM2), 230kBaud (COM3)

Process data size: 32 bytes per port input/output, 128 bytes per module input/output+4 bytes PQI

Device parameter memory size: 2kbyte (per port)

PROFINET interface:

Number of interfaces: 1

Transmission rate: Supports up to 100BASE-TX

Interface type: Integrated switch, supporting M12 ports

Functional features:

Support the backup function of the main station

Can be configured through the IO_LINK-MASTER function block

Support automatic start/manual function

Maximum cable length (unshielded): 20m

Operation mode:

Supports IO Link, Digital Input (DI), and Digital Output (DQ)

Maximum output current of 100mA in DQ mode

Physical characteristics:

Net weight: 0.631kg

Packaging size: 6.00 x 21.50 x 3.40 cm

Certification and Compliance:

Product certification: CE certification

Compliant with RoHS directive requirements
