SIEMENS 6ES7144-4PF00-0AB0 New and Original High quality

6ES7144-4PF00-0AB0

The 6ES7144-4PF00-0AB0 model product is a high-performance analog electronic module of the Siemens ET 200pro series, designed specifically for thermocouple signal acquisition and processing in industrial automation scenarios. Its core function is to integrate a 4-channel high-precision thermocouple (TC) input interface, support voltage signal conversion (measurement range ± 80mV) of various types of thermocouples such as B, E, J, K, L, N, R, S, T, and transmit real-time temperature data to the control system. This module has channel level diagnostic function, which can independently monitor the operating status of each channel. It is also compatible with the ET 200pro distributed I/O system and communicates with the main station through the PROFIBUS-DP bus. It is suitable for complex temperature monitoring scenarios in industries such as metallurgy, chemical engineering, and energy, and can accurately capture temperature fluctuations in the production process, providing reliable data support for process optimization and quality control.

Technical specifcations for 6ES7144-4PF00-0AB0

Basic information

Brand and Model: SIEMENS 6ES7144-4PF00-0AB0

Product type: Analog electronic module, belonging to the ET 200pro series

Purpose: Used for non electric control cabinet applications in machines, to achieve the acquisition and processing of analog signals

2、 Electrical parameters

Number of input channels: 4 channels, supporting multiple analog signal inputs

Signal type: Supports multiple analog signal inputs, which may include voltage, current, etc. (to be determined based on actual configuration)

Input range: The input range may vary for different types of analog signals (such as 0-10V DC, 4-20mA, etc., please refer to the specific product manual)

Accuracy and Resolution: Equipped with high-precision analog signal processing capabilities to ensure the accuracy and stability of data

3、 Communication and compatibility

Communication protocol: Supports communication protocols such as PROFIBUS-DP or PROFINET to achieve efficient data transmission with the main station

System Integration: Seamless integration with other modules in the ET 200pro series to build a distributed I/O system

Programming and Configuration: Programming and parameterized configuration are carried out through software such as STEP 7 to meet the needs of different application scenarios

4、 Environmental adaptability

Protection level: The ET 200pro system typically has a high protection level (such as IP65/66/67) and is suitable for harsh industrial environments

Working temperature range: able to work stably within a wide temperature range (specific range needs to refer to the product manual)

Electromagnetic compatibility: Complies with relevant electromagnetic compatibility standards to ensure stable operation in complex electromagnetic environments

5、 Functional characteristics

Hot swappable function: Supports hot plugging, facilitating online module replacement and maintenance

Diagnosis and alarm: Built in diagnostic function, can monitor the real-time operation status of the module, and alarm in a timely manner when a fault occurs

Isolation and protection: equipped with electrical isolation function, effectively preventing external interference from affecting the system; Simultaneously providing overvoltage, overcurrent and other protection functions to ensure system safety

6、 Installation and maintenance

Installation method: Supports rail installation for quick deployment inside the control cabinet

Wiring method: Provide convenient wiring methods, such as screw type or direct insertion front connectors, to simplify the wiring process

Maintenance and upkeep: Modular design facilitates replacement and maintenance, reducing maintenance costs; Provide detailed maintenance manuals and technical support to ensure the long-term stable operation of the system

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
