The 6ES7142-6BF50-0AB0 model product is a high-performance digital output module of Siemens ET200ECO PN series, belonging to the ET200 distributed I/O system. This module adopts a modular design and supports 8 digital output channels, each with an output current of 0.5A and a rated load voltage of 24V DC. It is suitable for connecting devices such as solenoid valves, DC contactors, and indicator lights. Its protection level reaches IP67, with a compact size (12.80 x 15.30 x 5.20cm) and a weight of 4.72kg, which can be stably connected through the M12 interface. The module supports the PROFINET communication protocol and can be integrated into the PROFIBUS-DP fieldbus network, suitable for scenarios in the industrial automation field that require high protection levels and reliable digital outputs.

Technical specifcations for 6ES7142-6BF50-0AB0

Model: 6ES7142-6BF50-0AB0

Brand: SIEMENS/Siemens

Structural form: modular

Installation method: modular

Working voltage: 24V DC

Output characteristics:

Number of output channels: 8 digital outputs

Output current: 0.5A per output

Rated load voltage: 24V DC

Protection level: IP67

Interface:

Communication interface: PROFINET

Connection method: 4 × M12

Size: 12.80 x 15.30 x 5.20cm

Weight: Approximately 4.72kg

Country of Origin: Germany

Functional features:

Diagnostic function: It can diagnose situations such as "1L+or 2L+missing", "output open circuit", "output to M short circuit", and can set the parameters that respond when the CPU/main station is in STOP state.

Redundancy function: supports priority startup and media redundancy.

Indicator lights: equipped with "SF/MT" (system comprehensive fault/maintenance) red/yellow LED indicator lights, "BF" (PROFINET IO bus monitoring) red LED indicator lights, "ON" (monitoring of power supply voltage 1L+) green LED indicator lights, "DC24V" (monitoring of power supply voltage 2L+) green LED indicator lights, "P1 LK" and "P2 LK" (network connection) green LED indicator lights, digital output green LED indicator lights, and digital output fault red LED indicator lights.

Readable diagnostic information: It can monitor 2L+faults, short circuits, open circuits (each channel is closed), and other situations.

Electrical parameters:

Power supply voltage: 1L+and 2L+are both 24V DC with reverse polarity protection.

Power supply current: 1L+and 2L+are both 4A.

Electrical isolation: Electrical isolation is achieved between 1L+and 2L+, 1L+, between channels and all other circuit components, between channels, and between Ethernet and all other circuit components.

Insulation test voltage: The Ethernet interface is 1500 Vrms (IEEE802.3, type test), and all other circuit components are 707 V DC (type test).

Current loss: The typical value of power supply voltage (1L+) is 100 mA, and the typical value of power supply voltage (2L+) is 5 mA.

Equipment power consumption: typical value of 3 W.

Output characteristic parameters:

Output quantity: 8

Status, Interruption, Diagnosis: Supports interrupt and diagnostic functions.

Transmission rate: 100 Mbps full duplex.

Transmission mode: 100BASE-TX, supports automatic negotiation.

Bus protocol: PROFINET IO, IRT with "high flexibility" option, supports PROFINET IO (device) ping, arp, LLDP network diagnostics (SNMP), DCP and other Ethernet services.

Manufacturer ID (Supplier ID): 002AH

Device ID: 0306H

Rated output voltage: 24V DC, for signal "1" less than 1L+/2L+(-0.8 V).

Output current: 0.5 A for signal "1" and 1.5 mA for signal "0" (residual current).

Load resistance range: 48 Ω to 3.3 k Ω.

Lamp load: 5 W, supports parallel connection of two outputs to enhance performance, and provides support for redundant control of the load.

Switching frequency: The resistive load is 100 Hz, the inductive load is 0.5 Hz, and the lamp load is 1 Hz. The typical limit value for the induced turn off voltage of the lamp load is 1L+/2L+(-47 V).

Output short circuit protection: Electronic type, with a typical response threshold of 0.7 A (per channel).

Cable length limit:

Shielded cable length: up to 30 meters.

Unshielded cable length: up to 30 meters.
