SIEMENS 6ES7138-4FA05-0AB0 New and Original High quality

6ES7138-4FA05-0AB0

The 6ES7138-4FA05-0AB0 model product is an electronic module used in the SIMATIC ET200S system. As a fail safe module, it has 4/8-point safety digital input (PROFIsafe) function, uses 24V DC power supply, has a structural width of 30mm, supports PL e (ISO 13849) and SIL 3 (IEC 61508) safety levels, and can be used for PROFINET network configuration through the IM 151-3 HF interface module. It is suitable for industrial automation scenarios that require high safety and reliability. At the same time, this product is a spare part that is exempt from mandatory product certification and is only used to provide maintenance services to end users.

Technical specifcations for 6ES7138-4FA05-0AB0

Type and Function:

Type: PROFIsafe digital input module, belonging to Siemens ET200S distributed I/O series.

Function: Used for fault safe reading of sensor information (single channel or dual channel), providing integrated deviation analysis of "2-out-of-2" signals.

Channel configuration:

Number of digital input terminals: 8 (single channel) or 4 (dual channel).

The input characteristics comply with IEC 61131, Type 1.

Electrical parameters:

Working voltage: 24V DC.

Rated current: 300mA.

Power loss: typical value of 4W.

Input voltage type: DC, rated value 24V.

Input current: For signal "1", the typical value is 3.7mA.

Performance level and safety standards:

Compliant with PL e (ISO 13849) and SIL 3 (IEC 61508) standards.

Support PROFIsafe protocol to achieve data communication.

Communication interface and network:

Supports PROFIBUS-DP and PROFINET (requires IM 151-3 HF interface module).

Input address space of 6 bytes and output address space of 4 bytes.

Environmental adaptability:

Working temperature: -20 ° C to+50 ° C (there are also data indicating that it can be extended to -20 ° C to+60 ° C, depending on the application scenario and configuration).

Protection level: IP20, suitable for installation inside control cabinets.

Physical dimensions and weight:

Size: 6.50 x 9.20 x 3.70cm (some sources indicate a width of 30mm, height and depth may vary depending on specific configuration).

Weight: Approximately 0.085kg.

Diagnostic and display functions:

Built in diagnostic function can help detect circuit faults and internal module issues.

Diagnostic display LED: Accumulated fault SF (red), digital input status display (green).

Potential isolation:

Digital input potential isolation: isolates between the channel and backplane bus.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
