SIEMENS 6ES7137-6CA00-0BU0 New and Original High quality

6ES7137-6CA00-0BU0

The 6ES7137-6CA00-0BU0 model product is a DALI master module in the Siemens SIMATIC ET 200SP series. Its core function is to achieve centralized management and control of lighting equipment under the DALI bus protocol by integrating a 160 mA power supply with the DALI Bus. This module supports communication for up to 64 DALI devices (which can actually connect to 63 control devices), complies with the DALI (Digital Address Programmable Lighting Interface) standard, and is suitable for large-scale lighting management systems, such as intelligent lighting scenarios in industrial plants, commercial buildings, and office buildings. Its hardware design is compatible with U0 type base units, using color code CC20 for system integration and device recognition. The modular structure supports quick installation and maintenance. As a component of a distributed I/O system, this module communicates with the master station through PROFINET or PROFIBUS bus and can work in conjunction with other I/O modules in the ET 200SP series to enhance system scalability. In the field of building automation, this module is capable of centralized management of lighting equipment, achieving energy optimization through precise control of switch status and brightness. At the same time, its high compatibility can seamlessly integrate into the Siemens automation architecture, meeting the demand for intelligent and energy-saving lighting control in the industrial and construction industries.

Technical specifcations for 6ES7137-6CA00-0BU0

Basic information

Brand: SIEMENS

Model: 6ES7137-6CA00-0BU0

Product type: DALI master station module, belonging to SIMATIC ET 200SP series

Purpose: Used for centralized management and control of lighting equipment on DALI bus

2、 Electrical parameters

Rated voltage (DC): 24V

Current consumption (rated value): 163mA

Power loss: 1.7W

Weight: Approximately 50g (some sources indicate 0.058kg)

Dimensions: 6.70 x 7.50 x 2.90cm (may vary slightly from different sources)

3、 DALI bus function

DALI bus power supply: Integrated 160mA power supply to provide the required power for connected DALI devices

Number of supported devices: Up to 64 DALI devices can be supported (63 control devices can actually be connected)

Color code: CC20, convenient for system management and recognition

Applicable base unit: U0 type base unit

4、 Communication and compatibility

Communication protocol: Supports DALI (Digital Address Programmable Lighting Interface) standard

System integration: Can work together with other I/O modules in the ET 200SP series to enhance system scalability

Software support: Programming and parameterized configuration through software such as STEP 7

5、 Environmental adaptability

Working temperature range: It can usually meet the requirements of industrial environments, and the specific range may vary depending on the product version and configuration (generally industrial grade equipment supports a range of -20 ℃ to+60 ℃ or wider)

Protection level: IP20 (for the module itself), suitable for installation inside control cabinets

6、 Functional characteristics

Hot swappable maintenance: supports online hot swappable to reduce system downtime

Fault diagnosis: Built in fault diagnosis mechanism, module comes with diagnostic indicator lights, and abnormal states can be quickly investigated

Redundant configuration: supports redundant channel configuration schemes to enhance system reliability

Parameter backup and recovery: By redundantly saving parameters to electronic coding components, IO Link device parameters (V1.1 devices only) and IO Link master station parameters can be automatically backed up without the need for programming tools
