SIEMENS 6ES7135-6HD00-0BA1 New and Original High quality

6ES7135-6HD00-0BA1

Hardware architecture:

Channel density: 16 channel design (50% increase in channel count compared to previous generation modules), supporting single module coverage of signal point requirements for medium-sized equipment, reducing the number of distributed sites.

Electrical isolation: 3000V AC photoelectric isolation between channels effectively suppresses the conducted noise of strong interference sources such as frequency converters/servo drives.

Wiring method: Dual versions of spring terminal and screw terminal are available, compatible with M8/M12 circular connectors, and adaptable to different wiring specifications in industrial sites.

Performance indicators:

Response speed: The typical signal capture delay is less than 500ns, meeting the sub millisecond control scenario requirements such as high-speed sorting and laser cutting.

Signal filtering: Programmable filtering time ranging from 0.2ms to 12.8ms, capable of filtering out false triggering caused by mechanical switch shaking or electromagnetic valve surge current.

Diagnostic depth: Supports channel level detection of ground short circuits, overloads, and disconnections, with fault localization accuracy up to a single input point.

Communication and Integration:

Bus performance: PROFINET RT Class 3 communication rate reaches 100Mbps, supports equal time synchronization mode (IRT), ensuring nanosecond level clock synchronization with the motion control module.

Topology compatibility: Supports linear/star/ring network redundant topologies, with a single link fault recovery time of less than 50ms, meeting high availability requirements such as automotive welding/lithium battery pack lines.

Engineering collaboration: By using TIA Portal to achieve integrated configuration of module parameters, HMI screens, and security logic, the project deployment cycle can be shortened by more than 30%.

Typical application scenarios:

Intelligent logistics: In the AGV scheduling system, real-time collection of shelf arrival signals, emergency stop button status, and safety light curtain feedback is carried out to ensure the safety of human-machine cooperation.

New energy manufacturing: In the production line of photovoltaic modules, precise collection of good/bad product signals from temperature switches and EL detectors of string welding machines is carried out to achieve closed-loop traceability of quality data.

Metallurgical industry: in the continuous casting machine mould vibration monitoring, high-frequency acquisition and edge computing are carried out for the proximity switch signal to warn of abnormal mechanical wear.

This module constructs a complete data chain from signal acquisition to edge decision-making through hardware redundancy design, software diagnostic enhancement, and communication protocol optimization, which meets the core demands of intelligent manufacturing for device state perception, production process transparency, and predictive maintenance.

Technical specifcations for 6ES7135-6HD00-0BA1

Product type and output capability

The model is an analog output module that supports 4-channel analog output (4XU/I standard type) and can output 0-20mA current signals or 0-10V voltage signals. It is suitable for continuous signal control scenarios in industrial automation.

Electrical parameters

The power supply voltage is 24V DC, compatible with mainstream industrial power standards;

The output accuracy reaches 16 bits, with an error range of ± 0.3%, ensuring high-precision control;

The module diagnostic function can monitor the output status in real time, improving system reliability.

Communication and Interface

Supports PROFIBUS and PROFINET communication protocols, compatible with various industrial network architectures;

Adopting A0 type base unit design, it is compatible with ET 200SP distributed I/O system, supports hot plugging, and is easy to expand and maintain the system.

Environmental adaptability

The working temperature range is -25 ° C to+60 ° C, meeting the extreme industrial environment requirements such as high temperature and low temperature;

The protection level meets industrial standards, has the ability to resist electromagnetic interference, and ensures signal stability.

application area

Widely used in electronic/battery manufacturing, road/rail/ship control, automotive and component production, electrical engineering and other scenarios to achieve precise analog control and regulation.
