SIEMENS 6ES7135-4FB00-0AB0 New and Original High quality

6ES7135-4FB00-0AB0

The 6ES7135-4FB00-0AB0 model product is a Siemens PROFIBUS DP protocol type fieldbus redundant link module, which belongs to industrial grade design and is suitable for a wide range of field environments. Its main function is to achieve mutual conversion between single bus and redundant dual bus. It can convert a single cable bus to a redundant PROFIBUS DP bus or a redundant PROFIBUS DP bus to a single cable bus. The speed can be set or selected adaptively through a dip switch, and supports 10 commonly used speeds of the PROFIBUS DP bus. This module has the performance of optocoupler isolation and interference reduction. It adopts IP30 protection level, corrugated aluminum reinforced housing, 35mm DIN rail installation, DC (9-36) V wide power input, relay alarm output, dual power redundancy and isolation protection. It can replace the brand ABB RLM01 (order number: 3BDZ000398R1) and can be directly placed after the PROFIBUS DP master station to convert a single cable bus into a redundant bus. It can also be placed at the slave station to convert a redundant bus into a non redundant cable, providing reliable bus redundancy and communication guarantee for industrial automation systems.

Technical specifcations for 6ES7135-4FB00-0AB0

Basic functions

Protocol support: Supports PROFIBUS DP protocol, which can achieve mutual conversion between single bus and redundant dual bus. It can convert single cable bus to redundant PROFIBUS DP bus or redundant PROFIBUS DP bus to single cable bus.

Redundancy design: Equipped with dual network redundancy function, the speed can be set or selected adaptively through a dip switch, supporting 10 commonly used speeds of PROFIBUS DP bus. Only one device is needed in the dual network redundancy system.

Modularization: Adopting industrial grade design, suitable for a wide range of on-site environments, it can be directly placed after the PROFIBUS DP master station to convert a single cable bus into a redundant bus, or placed at the slave station to convert a redundant bus into a non redundant cable.

2、 Electrical parameters

Protection level: IP30 protection level, corrugated aluminum reinforced casing, 35mm DIN rail installation.

Power input: DC (9-36) V wide power input, with dual power redundancy and isolation protection.

Output protection: It has the performance of optocoupler isolation, reducing interference, and short circuit protection to ensure output stability.

Alarm output: Equipped with relay alarm output, it can quickly locate faults and shorten downtime.

3、 Interface and Connection

Interface type: Provides fiber optic interface and DP bus interface, supports fiber optic ring network function.

Configuration flexibility: Supports dual power business and dual fiber interface design, supports point-to-point, star, chain bus, ring network, and hybrid network structures.

Transmission distance: Fiber optic long-distance transmission can reach over 20km, breaking through the distance limitations of cable systems.

Logical independence: The dual power business channel is logically independent and supports flexible combination of 1-2 optical/electrical interfaces. Multiple interface configurations can be implemented according to the actual needs of the project.
