SIEMENS 6ES7132-6HD01-2BB1 New and Original High quality

6ES7132-6HD01-2BB1

The 6ES7132-6HD01-2BB1 model product is a high-performance relay output module of Siemens SIMATIC ET 200SP series, designed specifically for industrial automation control scenarios. It adopts a compact modular structure and supports 4-channel normally open contact output (load capacity per channel) 5A@120V  DC/230V AC）， The B0/B1 base unit has electrical isolation characteristics and can be adapted to ET 200SP distributed I/O systems. It achieves efficient data exchange with PLC controllers through PROFINET or PROFIBUS bus. The built-in module diagnostic function can monitor the power supply voltage status in real time, suitable for industrial fields such as mechanical manufacturing, logistics transportation, water treatment, etc. that require low to medium load switch control. Its wide temperature working range (-25 ℃ to+60 ℃) and IP20 protection level ensure stable operation in complex industrial environments, and can be quickly configured and fault diagnosed through TIA Portal engineering software.

Technical specifcations for 6ES7132-6HD01-2BB1

Basic information

Brand and Model: SIEMENS, Model 6ES7132-6HD01-2BB1.

Product positioning: This module belongs to the ET 200SP distributed I/O system and is used for digital output control in industrial automation.

2、 Electrical parameters

Working voltage: The power supply voltage is 24V DC, with a lower limit (DC) of 19.2V and an upper limit (DC) of 28.8V.

Output characteristics:

Output type: Source Output.

Number of output channels: 4.

Load capacity: The maximum output current per channel is 2A, and the load voltage range that can be driven is 120V DC to 230V AC.

Reverse polarity protection: The module has a reverse polarity protection function, which can prevent damage to the module due to power connection.

Current consumption: The module itself consumes 60mA of current.

Power loss: The power loss of the module is 1W.

3、 Interface and Communication

Interface type: This module is connected to the system through the base unit (BU) of ET 200SP and supports data exchange with PROFINET or PROFIBUS bus.

Base unit adaptability: The module is suitable for B0 or B1 type base units.

4、 Environmental adaptability

Working temperature range: -30 ° C to+60 ° C, stable operation within a wide temperature range.

Protection level: The protection level of the module is IP20, suitable for installation inside industrial control cabinets.

5、 Mechanical and Installation

Module size: Width of 15mm, height of 73mm, depth of 58mm, weight of 30g, compact structure, easy to install.

Installation method: Supports DIN rail installation and can be quickly integrated into the ET 200SP distributed I/O system.

6、 Functional characteristics

Digital output type: The module provides 4 normally open contact outputs, with contact isolation to ensure electrical safety.

Diagnostic function: The module has diagnostic function, which can monitor the power supply voltage status for easy maintenance and troubleshooting.

Alternative value output: In the event of communication interruption or failure, the module can output preset values to ensure the continuous operation of the system.

7、 Application Fields

High voltage equipment control: suitable for controlling loads ranging from 120V DC to 230V AC, such as motors, lighting systems, heating equipment, etc.

Electrical isolation signal switching: suitable for applications that require complete isolation between the load and the control system, improving system safety.

Industrial Automation: Suitable for ET 200SP distributed I/O stations, it can remotely control different loads to meet the needs of industrial automation.
