SIEMENS 66ES7361-3CA01-0AA0 New and Original High quality

6ES7361-3CA01-0AA0

The 6ES7361-3CA01-0AA0 model product is the interface module IM 361 of Siemens S7-300 series PLC, specially designed for the expansion of distributed I/O systems. It is electrically connected to the central component bracket (IM360) through K-bus and supports deployment in the expansion component bracket. It can adapt to multiple CPU models (such as CPU 315-2 DP, CPU 317-2 PN/DP, etc.), and its 24V DC power supply and 5W typical power consumption design are suitable for industrial field power supply environments. The modular structure supports cascading expansion of up to 3 interface modules. Combined with STEP 7 programming software, it can achieve efficient communication with ET 200 distributed I/O devices, PROFINET IO controllers, and MPI master stations. It is widely used in industries such as automotive manufacturing and metallurgy. Automated production lines provide stable and reliable signal transmission solutions for distributed control systems.

Technical specifcations for 6ES7361-3CA01-0AA0

Basic information

Model: 6ES7361-3CA01-0AA0

Product Series: SIMATIC S7-300

Interface type: IM 361, used to connect to the central component bracket (IM360) in the expansion component bracket

Power supply voltage: 24V DC

Interface configuration: including K-bus

2、 Physical parameters

Net weight: 0.407Kg

Packaging size: 13.30cm × 15.40cm × 8.90cm

Dimensions: Width 80mm, Height 125mm, Depth 120mm

Structural form: modular

Protection level: IP20

Installation method: It can be installed on a DIN rail (slot 3) and connected to the I/O module through a bus connector

3、 Electrical and Performance Parameters

Number of input/output ports: 16 (specific configuration may vary depending on the application)

Working temperature range: -20 ℃ to+60 ℃ (some data mention an extended temperature range from -25 ° C to 70 ° C, suitable for special environments)

Allowable ambient temperature (Ta): maximum 60 ° C

Load power (Po): maximum 33.1mW

Output no-load voltage (Uo): maximum 10V

Fault voltage (Um): Maximum 60V DC/30V AC

Short circuit current (Io): maximum 13.9mA

Allow external capacitance (Co): maximum 3 μ F

Allow external sensitivity (Lo): maximum 80mH

Channel isolation test voltage: 500V DC or 350V AC

Electrical isolation between digital input channels and between channels and backplane buses: Yes

Number of points per group between channels: 12

Compliant with standards: EN 954-4, IEC 61508 SIL 2 (single channel), SIL 3 (dual channel)

Diagnostic alarm function: equipped with readable diagnostic information

4、 Functional characteristics

Automatic configuration: The interface module is self configuring, without the need for address allocation, reducing manual intervention during the configuration process, lowering the risk of configuration errors, and improving system debugging efficiency.

Support multi-layer expansion: When used in conjunction with IM360, it can achieve multi-layer expansion of S7-300 automation systems, connecting up to 3 expansion racks and installing up to 8 modules per rack.

Strong communication capability: Supports P bus (IO bus) and K bus (communication bus) to achieve high-speed and reliable data transmission between the expansion rack and the central rack.

Power supply method: An external 24VDC power supply is required to provide power for all modules on the expansion rack, which can be connected to the PS307 load power supply through a power connector.

Status monitoring: Equipped with status and fault LED indicator lights, it facilitates users to intuitively understand the working status of the module, and quickly diagnose and locate faults.

Protection function: It has functions such as overvoltage protection, overload protection, over temperature protection, short circuit protection, etc., to ensure stable operation of the system.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment

More Products In Stock:
