ProSoft MVI69-PDPMV1 Communication Module Good condition

ProSoft MVI69-PDPMV1 PROFIBUS DPV1 Master Communication Module

The MVI69-PDPMV1 is a ProfiBus DP V1 Master Network Interface Module. This module is used with the 1769 CompactLogix product family as well as the MicroLogix 1500 LRP. It has one (1) DB-9F optically isolated RS-485 communication port that is compatible for use with Profibus V1 protocol. This module supports communication up to 125 slaves and capable of up to 1536 cyclic bytes input and 1536 bytes output data.

Specifications：

Brand : ProSoft

Part Number/Catalog No. : MVI69-PDPMV1

Manufacturer : ProSoft Technology

Compatible Series : MicroLogix; CompactLogix

Module Type : ProfiBus DP-V1 Master communication module

Available ports : One (1) DB-9F optically isolated RS-485 port; One (1) configuration port

Supported electrical standards : RS485

No. of slaves : Up to 125 Profibus Slaves

Transmission speed : Up to 12 Mbps

Slot Width : Single slot

LED indicators : Power and Module Status LED; Application status LED; Serial port activity LED; Serial Activity and Error status LED

Backplane Current : 800 mA @ 5 V

Power supply distance rating : 2; First 2 slots if used with 1769-L43 and -L45

Operating Temperature : 32° F to 140° F (0° C to 60° C)

Storage Temperature : -40° F to 185° F (-40° C to 85° C)

Relative humidity : 5% to 95% (without condensation)

Product Type : PROFIBUS DP-V1 Master Network Interface Module

Rockwell Compatible Series : CompactLogix

Slot : 1

Data Transfer : Ladder Logic

Slave Modules : 125 max.

Output Data : 1536 bytes

Dimensions : Standard 1769 Single-slot Module

Current Load : 800 mA max. @ 5 VDC
