Omron S8JX-P60024C New and Original High quality

S8JX-P60024C

The S8JX-P60024C model is a DIN rail mounted switch mode power supply with an output power of 600W, capable of outputting 24V DC voltage and 27A current, suitable for the power supply needs of industrial automation equipment. It adopts a wide input design (AC100-240V), compatible with multiple national voltage standards, and has built-in power factor correction and EMI ClassB filtering technology, effectively reducing harmonic interference. The product complies with international safety certifications such as UL and EN, supports front or rail installation, and is equipped with triple protection mechanisms for overload, overvoltage, and overheating. When the output current exceeds the set value by 105% to 160%, the current limiting protection is automatically triggered. When the output voltage exceeds 130% of the rated value, the power supply is cut off and a red light alarm is displayed. In addition, it adopts a natural air-cooled heat dissipation structure and can operate at full load at an ambient temperature of 40 ℃. It supports remote sensing compensation function and can automatically compensate for the load line voltage drop through the+S/- S terminal to ensure stable terminal voltage. This model is widely used in industrial scenarios such as CNC machine tools, packaging machinery, logistics sorting systems, etc. due to its high power density, compact size (239.8 × 77.6 × 118.5mm), and IP20 protection level.

Technical specifcations for S8JX-P60024C

Basic electrical parameters

Input voltage range: AC85V to 264V (compatible with global power grid fluctuations)

Output specification: 24VDC/27A (rated output power 600W)

Efficiency characteristics: Typical efficiency up to 90%, no-load power consumption less than 1W

Voltage regulation rate: ± 0.5% (output voltage stability during load fluctuations)

Load adjustment rate: ± 1% (output stability when input voltage changes)

2、 Installation and Protection Standards

Installation method: Supports 35mm standard DIN rail installation

Protection level: IP20 (excluding exposed areas of terminal blocks)

Insulation resistance: Input/output terminal to ground ≥ 500M Ω (DC500V test)

Voltage resistance: Input to output/ground 3000VAC/1 minute without breakdown

3、 Environmental adaptability

Working temperature: -20 ℃ to+70 ℃ (full load output)

Storage temperature: -40 ℃ to+85 ℃

Humidity range: 5% to 95% RH (no condensation)

Altitude adaptation: ≤ 5000 meters (used for power derating)

4、 Protection and monitoring functions

Overload protection: automatic current limiting at 105% -150% rated load

Short circuit protection: constant current output in case of output short circuit, automatically restored after fault relief

Overvoltage protection: Cut off output when output voltage exceeds 28.8V

Overheating protection: Start load reduction when the internal temperature reaches 85 ℃, and turn off when it reaches 90 ℃

Status indication: Dual color LED displays power/fault status

5、 Electromagnetic compatibility and certification

EMC standard: Complies with EN55011 Class B (Conducted/Radiated)

Safety certification: UL60950-1, EN60950-1, CQC certification

Harmonic suppression: meets the IEC61000-3-2 Class D standard

Immunity: Complies with IEC61000-4-2 to 6 standards

6、 Mechanical and electrical interface

Size specifications: 239.8mm (width) x 77.6mm (height) x 118.5mm (depth)

Weight: Approximately 1.2kg

Wiring terminal: Screw terminal supports AWG14-22 wire diameter

Grounding resistance: ≤ 100m Ω (from the grounding terminal to the casing)

7、 Extended functionality

Remote control: optional remote ON/OFF control signal input

Voltage fine-tuning: supports ± 10% output voltage adjustment

Parallel redundancy: 3 units can be connected in parallel to achieve N+1 redundant power supply

Remote signaling alarm: provide fault dry contact signal output

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
