Omron NX-PD1000 3 New and Original High quality

NX-PD1000    3

The NX-PD100 series power module (if there is a specific "3 model" subdivision, its core characteristics should maintain technical continuity with the standard model) is a high reliability power unit designed for NX series automation controllers. It adopts a compact DIN rail mounting structure (12mm wide), supports 24VDC DC power supply (input range DC20.4V-28.8V), and has a maximum output power of 10W (typical current 0.41A). It can provide stable power distribution for NX series I/O modules, EtherCAT couplers, and CPU units. Its core advantages include: 1) integrated FG terminal expansion function, supporting the grounding shielding requirements of industrial field equipment; 2) Adopting a screw free spring terminal design significantly reduces the complexity of on-site wiring and improves maintenance efficiency; 3) Through RoHS certification and IP20 protection level, it ensures stable operation in industrial environments with 0 ℃~55 ℃ and 10%~90% RH (no condensation), especially suitable for automation scenarios such as automotive manufacturing and packaging machinery that require high-density power distribution. It can be seamlessly integrated with CPU units such as NX1P2 and NX102, serving as a key power supply component for distributed control systems.

Technical specifcations for NX-PD1000    3

Basic electrical parameters

Input voltage range: DC20.4V~28.8V (compatible with 24VDC industrial power standard)

Output power: Maximum 10W (typical current) 0.41A@24VDC ）

Power efficiency: 70%

Unwired terminal current capacity: below 4A (including through wiring current)

Insulation resistance: ≥ 20M Ω between enclosed circuits (at DC100V)

Voltage endurance: AC510V/1 minute between enclosed circuits (leakage current ≤ 5mA)

Mechanical and installation parameters

Dimensions: 12mm (width) x 100mm (height) x 71mm (depth)

Weight: ≤ 65g

Installation method: Supports DIN rail 6-direction installation, compatible with compact control cabinet layout

Terminal type: Screw free spring terminal block (8 terminals), reducing wiring complexity

Environmental adaptability

Working temperature: 0 ℃~55 ℃

Storage temperature: -25 ℃~70 ℃ (without condensation or freezing)

Humidity range: 10%~90% RH (no condensation)

Altitude: ≤ 2000m

Pollution level: 2 or below (compliant with IEC 61010-2-201)

Electromagnetic compatibility and certification

Electromagnetic compatibility:

Resistance to power line interference: 2kV (compliant with IEC61000-4-4 standard)

EMC immunity level: Zone B

Vibration resistance: 5~8.4Hz (amplitude 3.5mm), 8.4~150Hz (acceleration 9.8m/s ²), 100 minutes in X/Y/Z direction each

Impact resistance: Complies with IEC 60068-2-27 standard

Security certification:

CULus: Certified by UL508 and ANSI/ISA 12.12.01

EU: CE, C-Tick, KC registration

Other: Lloyd, NK certification

Environmental standards: Compliant with RoHS3 specifications, moisture sensitivity level MSL1 (unlimited)

function characteristics

Grounding requirement: Grounding resistance ≤ 100 Ω

NX unit power consumption: ≤ 0.45W

I/O current consumption: No consumption

Overvoltage level: Level II (compliant with IEC 61010-2-201)

Installation direction: Supports 6-directional free installation without special restrictions

Expansion and Compatibility

Through wiring: Additional NX units or EtherCAT connectors can be powered through un wired terminals (UV/UG)

System compatibility: Seamless integration with NX series controllers (such as NX1P2, NX102), supporting distributed control systems
