Omron NX-ID5142-1 8 New and Original High quality

NX-ID5142-1    8

The NX-ID5142-1 model product is a digital input unit module designed specifically for industrial automation. Its core function is to provide high-precision and high reliability digital signal acquisition capabilities, suitable for use with NX series CPU units (such as NX1P2) and EtherCAT coupler units to achieve equipment status monitoring and logic control. This module supports 16 channel NPN/PNP shared digital inputs and uses M3 screw terminal blocks for signal connection, ensuring stable electrical performance even in industrial environments such as strong vibration and high humidity; Its input voltage range is DC24V (DC20.4-28.8V), which is compatible with various sensors and switch devices. The synchronous I/O refresh mode and free running refresh mode are optional, and the conversion time is lower than the typical value, meeting the requirements of high-speed synchronous measurement; The module supports a wide temperature range (0-56 ℃) and a humidity environment of 10% -90% RH. The pollution level meets the IEC 61010-2-201 standard, and the protection level reaches IP20. It is suitable for complex industrial scenarios such as automobile manufacturing and packaging machinery, and serves as a key component to enhance system response speed and anti-interference ability.

Technical specifcations for NX-ID5142-1    8

Basic electrical parameters

Input type: DC input, supports NPN/PNP shared signals, compatible with multiple sensor output types.

Input points: 16 channels, which can meet the requirements of multi-channel signal acquisition.

Rated voltage: DC24V (voltage range DC20.4V to 28.8V), suitable for power fluctuations in industrial sites.

Refresh mode: Supports synchronous I/O refresh or free running refresh mode, and users can flexibly configure according to system requirements.

Conversion time: Typical value below 250 μ s/channel, suitable for high-speed synchronous measurement scenarios.

2、 Mechanical and installation parameters

Dimensions: The module dimensions are 104.5mm (width) x 95mm (height) x 30mm (depth), with a compact structure that saves cabinet space.

Installation method: Supports modular installation, can be installed through DIN rails or panels, and is compatible with various industrial control cabinet layouts.

Terminal type: M3 screw terminal block is used to ensure stable signal connection and is suitable for vibration environments.

Weight: Approximately 70g, lightweight design for easy installation and maintenance.

3、 Environmental adaptability

Working temperature: 0 ℃ to 56 ℃, capable of stable operation in high-temperature industrial environments.

Storage temperature: -25 ℃ to 70 ℃, suitable for device storage needs in extreme environments.

Humidity range: 10% to 90% RH (no condensation or freezing), suitable for humid industrial environments.

Altitude adaptation: It can be used in environments below an altitude of 2000m to ensure equipment stability in high-altitude areas.

Pollution level: Complies with IEC 61010-2-201 standard, pollution level 2 or below, suitable for general industrial environments.

4、 Electromagnetic compatibility and certification

Electromagnetic compatibility: Compliant with electromagnetic compatibility standards such as IEC61000-4-4, effectively resisting electromagnetic interference.

Safety certification: Through international safety certifications such as UL508, ANSI/ISA 12.12.01, EN 61131-2, etc., ensure the safety of equipment in industrial environments.

Anti interference capability: Resistant to power line interference of 2kV (compliant with IEC61000-4-4 standard), ensuring the accuracy of signal acquisition.

5、 Functionality and Scalability

Data storage capacity: 2K steps, capable of storing a certain amount of program or configuration data.

Program capacity: 256kbyte (mentioned in some materials), supporting complex logic control requirements.

Output type: Relay output (mentioned in some materials), can drive various load devices.

Interface and Protocol: Supports RS-485 interface, communication protocol includes EtherNet/IP (mentioned in some materials), facilitating system integration and expansion.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
