Omron G9SP-N20S New and Original High quality

G9SP-N20S

The G9SP-N20S model is a high-performance safety controller belonging to the G9SP series. It adopts a compact design, supports 24VDC power supply, has 20 digital inputs and 8 solid-state safety outputs, adopts PNP output mode, and has a rated output current of up to 300mA (single point) or 120mA (test output multi-channel total), meeting the high-precision control requirements of safety signals in the industrial automation field. This product has passed international certifications such as CE, cUL, T Ü V, etc., and complies with safety standards such as EN ISO 13849-1 and IEC 61508. It has built-in anti-interference circuits and overvoltage protection functions, ensuring stable operation in working temperatures ranging from 0 ℃ to 55 ℃ and humidity environments ranging from 10% to 90%. It supports DIN rail or M4 screw installation and is suitable for mechanical safety protection, automated production lines, and other scenarios. By expanding the I/O unit, system compatibility can be further enhanced.

Technical specifcations for G9SP-N20S

Power parameters:

Working power supply voltage: 24VDC (20.4V to 26.4V, fluctuation range of -15% to+10%), in accordance with Class III (SELV) insulation structure, overvoltage level II.

Current consumption: The total current consumption is 500mA, of which V1 (internal circuit) is 400mA and V2 (output circuit) is 100mA.

Input and output parameters:

Safe input: 20 point digital input, leakage type input (corresponding to PNP), input current of 6mA, ON voltage above DC11V (between each input terminal and G1), OFF voltage below DC5V (between each input terminal and G1), OFF current below 1mA.

Safe output: 8-point solid-state safe output, source type output (corresponding to PNP), rated output current is below 0.8A per point and below 1.6A per 4-point (G9SP-N20S model). ON residual voltage below 1.2V (between each output terminal and V2), OFF residual voltage below 2V, leakage current below 0.1mA.

Test output: 6-point test output, output type is source output (PNP type), rated output current at T0, T1, T2 points is below 100mA, T3 point is below 300mA, T4 and T5 points are below 30mA, total output current at T0-2 and T4-5 points is below 120mA, ON residual voltage is below 1.8V (between each output terminal and V1), leakage current is below 0.1mA.

Environmental parameters:

Operating environment temperature: 0 ℃ to+55 ℃.

Operating environment humidity: 10% to 90% (no condensation).

Storage environment temperature: -20 ℃ to+75 ℃.

Usage altitude: below 2000m above sea level.

Pollution level: Level 2 pollution.

Atmospheric environment: No corrosive gases.

Mechanical and installation parameters:

Protection level: IP20 (excluding terminal blocks).

Installation method: Supports DIN rail installation (IEC60715 TH35-7.5/TH35-15) or M4 screw installation (torque 1.2N · m).

Dimensions: Please refer to the product manual for specific dimensions, with a weight of approximately 430g.

End connection style: screw terminal.

Anti interference and durability parameters:

Anti interference performance: compliant with IEC61131-2 standard.

Vibration resistance: 3.5mm at 5-8.4Hz, 9.8m/s ² at 8.4-150Hz.

Impact resistance: 147m/s ², lasting for 11ms.

Certification and standard parameters:

Certification bodies: CE, cUL, T Ü V.

Compliant with safety standards such as EN ISO 13849-1 and IEC 61508.

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
