KEYENCE OP-88778 New and Original High quality

OP-88778

The OP-88778 model product is a high reliability connection cable assembly designed specifically for industrial sensors and vision systems. It adopts a 5-meter standard wire length configuration and is compatible with Keyence SR series scanners, IV series image sensors, and laser contour measuring instruments. It achieves signal direct connection through M8 and C interface dual end connectors and supports extreme environmental operation from -50 ° C to+100 ° C. Its core structure adopts double-layer shielded tinned copper conductors and oil resistant PVC sheaths. It has been verified through 100000 dynamic bending tests, and the outer diameter of the cable is suitable for wiring requirements in narrow spaces. At the same time, it integrates an anti electromagnetic interference layer (attenuation ≥ 65dB) and IP67 protection level, which can resist dust, water vapor, and mechanical vibration impact in industrial sites. This model is equipped with an anti pull off locking device and cable fixing buckle, supporting a tensile strength of ≥ 50N, suitable for high-speed sorting lines of automotive parts, precision detection of electronic components, and other scenarios. It is particularly suitable for the collaborative work of the Keyence SR-2000W laser scanner and IV-HG500CA image sensor, achieving a signal transmission accuracy of ± 0.1mm through customized line sequence matching, and compatible with the expansion requirements of polarizer accessories (OP-87899 series) and circular lighting auxiliary modules (IV-GD05/IV-GD10), ensuring the stability of data transmission in strong electromagnetic interference or high humidity environments.

Technical specifcations for OP-88778

Electrical parameters:

Voltage range: Supports wide range power input from 2V to 9V, adapted to the power supply needs of different industrial equipment, ensuring stable operation even in voltage fluctuation environments.

Cable specifications: Adopting customized shielded twisted pair structure, wire diameter 1.8mm × 9.1mm × 1.5mm (length × width × height), balancing flexibility and tensile strength, suitable for complex wiring scenarios.

Environmental adaptability:

Protection level: Meets IP67 standard, can completely prevent dust and withstand immersion in 1 meter of water for 30 minutes, suitable for industrial environments with high dust, humidity, or requiring regular flushing.

Working temperature range: -50 ° C to+100 ° C, able to maintain signal transmission stability even under extreme temperature differences, meeting the needs of high-altitude or high-temperature workshops.

Mechanical properties:

Bending resistance test: Through 100000 dynamic bending tests (with a bending radius of 5 times the wire diameter), ensure that the cable does not break in frequent moving or vibration scenarios.

Interface strength: The M8 and C interfaces are designed with gold-plated contacts, with a plug-in life of ≥ 5000 times and a contact resistance of ≤ 10m Ω, ensuring reliable signal transmission.

Electromagnetic compatibility:

Shielding effectiveness: double-layer aluminum foil+tinned copper braided shielding layer, electromagnetic interference attenuation ≥ 65dB (10MHz-1GHz), effectively resisting electromagnetic noise generated by frequency converters, motors and other equipment.

Grounding design: The cable is equipped with an independent grounding wire to ensure rapid discharge of static electricity and transient overvoltage, protecting sensitive electronic components.

Compatibility and Scalability:

Equipment adaptation: Compatible with the entire range of devices such as Keyence SR series scanners, IV series image sensors, and laser profilometers, supporting plug and play functionality.

Attachment extension: Can be paired with OP-87899 series polarizer accessories and IV-GD05/IV-GD10 circular lighting modules to meet the needs of special detection scenarios.

Installation and maintenance:

Fixed device: Integrated cable fixing buckle and anti pull off locking device, supporting a tensile strength of ≥ 50N to prevent loose connections caused by mechanical vibration.

Identification system: The cable surface is printed with model, length, and direction markings for quick identification and maintenance.
