KEYENCE IV-HG600MA New and Original High quality

IV-HG600MA

The IV-HG600MA model product is a wide field image recognition sensor equipped with a 1/3-inch black and white CMOS image receiving element, with a pixel count of 752 (horizontal) × 480 (vertical), supporting automatic focus adjustment, and exposure time adjustable within the range of 1/50 to 1/50000. The sensor adopts infrared LED pulse lighting method, equipped with 2 status indicator lights, with a protection level of IP67, an environmental temperature adaptation range of 0 to+50 ° C (no freezing), and a relative humidity of 35 to 85% RH (no condensation). Its seismic resistance ranges from 10 to 55Hz, with a double amplitude of 1.5mm and a duration of 2 hours in each X/Y/Z direction. Its impact resistance reaches 500m/s ² (3 times in each of the 6 directions). In terms of material, the main device housing is made of zinc casting, the front cover plate is made of acrylic resin (hard coating), and the action indicator light cover plate is made of TPU. This product supports installation with a wide field of view, with installation distances ranging from 40 to 600mm, corresponding to a field of view range from 42 (horizontal) × 31 (vertical) mm to 550 (horizontal) × 412 (vertical) mm. It has high-precision image recognition capabilities and is suitable for object detection, positioning, and recognition tasks in industrial automation scenarios.

Technical specifcations forIV-HG600MA

Model and type

model: IV-HG600MA

Type: Wide field of view type

Installation and View

Installation distance: 40 to 600mm

Field of view: When installed at a distance of 40mm, it is 42mm horizontally and 31mm vertically; When the installation distance is 600mm, the horizontal distance is 550mm × vertical distance is 412mm

Image receiving component

Type: 1/3-inch black and white CMOS

Pixel count: 752 (horizontal) × 480 (vertical)

Focus adjustment and exposure time

Focus adjustment: Automatic (can automatically adjust the focus position during installation, does not move during operation, can register the focus position according to the program)

Exposure time: 1/50 to 1/50000

Lighting and indicator lights

Light source: Infrared LED

Lighting method: Pulse lighting

Indicator lights: 2 lights (displaying the same content)

Environmental resistance

Shell protection level: IP67 (except when installing polarizer accessories)

Environmental temperature: 0 to+50 ° C (no freezing)

Relative humidity: 35 to 85% RH (non condensing)

Seismic resistance: 10 to 55Hz, double amplitude 1.5mm, 2 hours each in X, Y, and Z directions (excluding installation of IV-HG circular lighting auxiliary accessories)

Impact resistance: 500m/s ², 3 times in each of 6 directions (except when installing IV-HG circular lighting auxiliary accessories)

material

Main device housing: Zinc casting

Front cover plate: Acrylic resin (hard coating)

Action indicator light cover: TPU

other

The image receiving component also has a 1/3-inch color CMOS option

The automatic exposure time range for focus adjustment includes different parameters such as 1/10 to 1/50000, 1/20 to 1/50000, and 1/25 to 1/50000 (which may vary depending on specific configurations or usage scenarios)

Our Services:

1、All our products are new and orginal, and of good quality

2、Our prices are very competitive.

3、 We have a large quantity in stock, so we could help the customers to get the components which are dificult to get.

4、All inquiries will be valued and will reply in 24.

Packing & Delivery:

1、100% brand New and Original Factory Seal!

2、Warranty:1 year

3、Package: Original packing with cartons.

4、Delivery time: Shipped in 3-7 days after payment

5、All the goods will be tested before shipment
