KEYENCE GT2-P12KF New and Original High quality

GT2-P12KF

The GT2-P12KF model product is a high-precision contact type digital displacement sensor head, designed with a pen and equipped with a flange installation method. It has a resolution of 0.1 μ m and a precision of 1 μ m (p-p), with a measurement range of 12 mm. It is equipped with the "Scale Pulse System II" detection principle to achieve absolute measurement (without tracking error). Its mechanical response frequency reaches 10 Hz, sampling period is 4 ms, and the measurement force is dynamically adjusted according to the installation direction (downward 1.0 N, horizontal 0.95 N, upward 0.9 N). The environmental resistance meets IP67G (JIS) and IP67 (IEC) standards, and also meets NEMA Type 13 oil intrusion prevention requirements. It can operate stably in a temperature range of -10 to+55 ° C and a humidity environment of 35 to 85% RH. The sensor body is made of SUS303 casting, with a built-in stainless steel spindle and high hardness linear ball bearings, achieving a detection life of 100 million times. The cable is made of oil resistant PUR material, and the relay connector is made of PBT material. It can be flexibly wired from 2 to 10 meters through M8 oil resistant cables (such as GT2-CHP2M/CHP5M/CHP10M), compatible with USB and PLC communication interfaces, suitable for high-precision industrial scenarios such as automotive parts detection and precision machining.

Technical specifcations for GT2-P12KF

Detection system and accuracy

Detection system: Scale pulse system II (absolute type, no tracking error)

Measurement range: 12 mm

Resolution: 0.1 μ m

Accuracy: 1 μ m (p-p)

Measurement force and response

Measurement force:

Downward installation: 1.0 N

Horizontal installation: 0.95 N

Upward installation: 0.9 N

Sampling period: 4 ms

Mechanical response: 10 Hz

Environmental parameters

Working temperature: -10 to+55 ° C (without freezing)

Relative humidity: 35 to 85% RH (non condensing)

Seismic resistance: 10 to 55 Hz, double amplitude of 1.5 mm, 2 hours each in the X, Y, and Z directions

Impact resistance: 1000 m/s ² (IEC60068-2-27)

Shell protection level: IP67G（JIS）、IP67（IEC）、NEMA Type 13

Material and Structure

Main body: SUS303 casting

Status indicator light: PET

Cable between sensor head and relay connector: PUR (oil resistant)

Relay connector: PBT

a dust cover: NBR

Contact components: SUS304、SUS440C

Installation and compatibility

Installation method: flange installation

Cable specification: M8 oil resistant cable (GT2-CHP2M/CHP5M/CHP10M)

Compatibility: Compatible with USB and PLC communication interfaces

Application and advantages

Application areas: high-precision industrial scenarios such as automotive parts testing, precision machining, and electronic manufacturing

Advantages: High precision, high durability (100 million test life), lightweight design, oil and corrosion resistance, seamless construction reduces the risk of water and oil corrosion

This model of product is suitable for industrial applications that require extremely high measurement accuracy and environmental adaptability through high-precision detection principles and sturdy and durable construction.
