KEYENCE GT2-71P New and Original High quality

GT2-71P

The GT2-71P model product is a high-precision contact type digital sensor amplifier unit, designed with DIN rail PNP output, supporting 10 to 30 VDC power supply voltage (including 10% ripple), with a maximum power consumption of 2200 mW in standard mode (73.3 mA at 30 V) and 1700 mW in power-saving mode (56.7 mA at 30 V). The measurement value display is a 6+1/2 bit 7-segment LED (red), paired with a 2-color 13 level bar LED display (red, green) and indicator lights, covering a display range of -1999.999.9 to 1999.999.9, with a resolution of 0.1 μ m. Control output supports HH/HI/GO/LO/LL PNP collector open circuit, maximum 30 V 50 mA, residual voltage maximum 1 V, response time optional 3/5/10/100/500/1000 ms (12/20/40/400/2000/4000 ms when using GT2 Pxxx). This product complies with UL/CSA standards and has environmental resistance including -10 to+50 ° C operating temperature, 35 to 85% RH relative humidity (non condensing), 10 to 55 Hz dual amplitude 1.5 mm seismic resistance (2 hours in X, Y, Z directions each). The main body shell is made of polycarbonate, the touch keys are made of polyoxymethylene, the front panel is made of PET, and the cable is made of PVC. Its installation method is DIN rail installation, suitable for high-precision measurement requirements in industrial automation control.

Technical specifcations for GT2-71P

Electrical parameters

Power supply voltage range: 10 to 30 VDC (including 10% ripple)

Power consumption:

Standard mode: Maximum 2200 mW (73.3 mA at 30 V)

Power saving mode: maximum 1700 mW (maximum 56.7 mA at 30 V)

Control output:

Type: PNP collector open circuit

Maximum voltage: 30 V

Maximum current: 50 mA

Residual voltage: maximum 1 V

Display parameters

Measurement display: 6+1/2 bit 7-segment LED (red)

Bar display: 2-color 13 level (red, green)

Indicator lights: red, green

Display range: -1999.999.9 to 1999.999.9

Display resolution: 0.1 μ m

response time

Optional: 3/5/10/100/500/1000 ms (12/20/40/400/2000/4000 ms when using GT2 Pxxx)

Environmental parameters

Working temperature: -10 to+50 ° C (without freezing)

Relative humidity: 35 to 85% RH (non condensing)

Seismic resistance: 10 to 55 Hz, double amplitude of 1.5 mm, 2 hours each in the X, Y, and Z directions

Material and Structure

Main body shell: polycarbonate

Touch key: polyoxymethylene

Front panel: PET

Cable: PVC

Installation method

DIN rail installation

other characteristics

Compliant with UL/CSA standards

Control inputs: timing/preset/reset/channel input (no voltage input)

Control output options: HH/HI/GO/LO/LL
