HE693RTD601 High Speed Counters
Each counter provides direct processing of rapid pulse signals up to 10kHz for industrial control applications such as meter proving, turbine flowmeter, velocity measurement, material handling, motion control, and process control. Each counter can be enabled independently. Type A counters can be configured for up or down counting (default is up) and for positive or negative edge detection (default is positive). The type B counter provides an A Quad B counting function. Nano PLCs with DC outputs provide up to 3 High-Speed Counter outputs, and/or Pulse Train or Pulse-Width Modulated outputs.
HE693RTD601 DC Power Specifications
| Range | 9.6VDC - 15VDC |
| Hold-up | 3.0mS |
| Inrush Current | 8A typical at 12 VDC |
| Inrush Time | 200mS typical |
| Input Current | 250mA typical at 12 VDC |
| Input Power Supply Rating | 3W |
Wiring Diagram
