FLEX I/O Modules

Our Bulletin 1794 FLEX? I/O modules are flexible for applications that use digital, analog, HART analog, and special I/O, with 4 to 32 points per module. You can mix and match digital and analog I/O with installation and wiring options.

With modular design, you can independently and flexibly select I/O, terminal type and network interface

Support various applications through digital, analog and professional modules

It adopts convenient snap in installation, supports hot plug (RIUP), and allows users to replace modules and connect cables during system operation

FLEX I/O-XT? The extreme environment module is rated at - 20 to 70 ° C (- 4 to 158 ° F) and is compatible with ControlLogix XT? System compatibility in extreme environments

Provide conformal coating module

Each I/O module requires a terminal with connection points for I/O wiring

1794 FLEX I/O Digital Module

Wide electrical coverage

Density is 8 - 32 points

Isolated inputs or outputs, protected outputs, electronic fuses, or diagnostics are available on some modules

1794 FLEX I/O Analog Module

Individually configurable channels

Many modules have selectable input filters

Single ended or differential input

On board setting

Internal calibration

Provide thermocouple, thermal resistance and HART (addressable remote sensor data path) modules

1794 FLEX I/O Special Modules

Frequency module

Ultra high speed counter module

Pulse counter module

1794-TB3 1794-AENT 1794-AENTR 1794-TB32 1794-IB16 1794-IE12 1794-IB32 1794-IE8 1794-TB3G 1794-OB16 1794-OB32P 1794-OW8 1794-IA16 1794-OA16 1794-OE4 1794-OE12 1794-TBN 1794-IT8 1794-IF4I 1794-IR8 1794-TB2 1794-ACNR15 1794-IM16 1794-OB16P 1794-PS13 1794-IRT8 1794-ACN15 1794-ADN 1794-IE8XOE4 1794-PS3 1794-TB3T 1794-CE3 1794-IB16D 1794-TB3S 1794-IE4XOE2 1794-OF4I 1794-IB16XOB16P 1794-IE8H 1794-IF8IH 1794-VHSC 1794-IB10XOB6 1794-OM16 1794-IB8 1794-OV16 1794-CE1 1794-IF2XOF2I 1794-TBNF 1794-OF8IH 1794-IV16 1794-OB8 1794-TB32S 1794-IF4IXT 1794-TB3TS 1794-IA8 1794-OA8 1794-IP4 1794-OA8I 1794-OB16D 1794-ID2 1794-IE8XT 1794-N2 1794-OB16PXT 1794-OB8EPXT 1794-OE8H 1794-OW8XT 1794-ASB 1794-OB8EP
