In the realm of industrial automation, communication efficiency andcompatibility between devices directly impact the flexibility and stability ofproduction systems. The ProSolt MVls6E-MNETCR module stands out as acore componentfor connecting heterogeneousnetworks, thanks to its robustprotocol conversion capabilities, high-reliability design, and adaptability todiverse scenarios.

l. Technical Specifications

1.Communication Protocol support

• Multi-Protocol Compatibility: Supports mainstream industrial protocols suchas Modbus TCP/IP, Modbus RTU/ASCll, Enron, and Daniel@. lt can operateconcurrently as a client or server, meeting the protocol conversion needs ofdifferent devices.
• Network Interface: Equipped with a 10/100Mbps Ethernet port featuringautomatic crossover cable detection. Data transmission rates can reach up to1soMbps(leveraging Wi-Fi/Bluetooth auxiliary functions)to ensurereal-time performance.

2. Electrical and Physical Characteristics

• Operating Voltage: 220V AC input with a 3okHz output frequency,compatible with industrial-standard power environments.
• Environmental Adaptability: Operates in temperatures ranging from -40°Cto 8s°C. While the lp rating is not explicitly stated, its industrial-gradedesign ensures stable operation in harsh conditions such as hightemperatures and dusty environments.
• Dimensions and Installation: The module measures 2smm x 15mm x 2.5mm(wireless module portion). lts compact design facilitates easy integration intocontrol cabinets and supports DiN rail or panel mounting.

3. l/O and Data Processing

• I/O Configuration: Supports expansion to 0/120/240 points, with datatypes covering 16-bit integers, floating-point numbers, and strings to meetmixed analog/digital data acquisition needs.
• Communication Rate: Serial port baud rates are adjustable from 110 to11s,200bps, with support for 12 stop bits, 7/g data bits, andno/odd/even parity, ensuring compatibility with legacy devices.

ll. Core Functions: The "Translator" Breaking Protocol Barriers

1. Protocol Conversion and Data Bridging

The module maps EtherNet/lp data from Rockwell AutomationContrologix@ or Compactlogix" PLCs to Modbus TCP/lp networks,enabling cross-platform communication. For example, in energy

management systems, it transmits meter data collected by PLGs to SCADAsystems via Modbus TCP/IP.

2. Multi-Client/Server Architecture

A single module supports up to 30 Modbus client connections and 20 serverconnections. when paired with redundancy configuration, it automaticallgswitches to backup paths if the primary server goes offline, ensuringuninterrupted data flow.

3. Remote Diagnostics and Maintenance

Using the ProSolk Configuration Builder tool, users can remotely modifymodule parameters, upload/download programs, and leverage built-inerror codes, counters, and status logs to quickly locate faults.

4. Security and Certification

Supports WPA2 encryption and AEs-CMP data protection, with acommunication range ofup to 100 meters(Wi-Fi mode), adhering toindustrial eyberseeurity standards.

Ill. Application Areas: Cross-Industry Empowerment fromManufacturing to Energy

1. Manufacturing Automation

In automotive production lines, the MVls6E-MNETCR integrates devicessuch as motor drives and temperature controllers, enabling real-time

production data acquisition and dynamic adjustment ofprocess parameters.For instance, it feeds back inverter status to PLCs via Modbus TCP/lp tooptimize welding robot motion timing.

2. Energy and Infrastructure

In wind farms, the module converts EtherNet/lp data from wind turbineRCs to Modbus RTU for transmission to local monitoring terminals, whilealso supporting remote diagnostics of turbine vibration sensor data.

3.Water Treatment and Environmental Protection

In wastewater treatment plants, it connects level meters, flow meters, andother devices from different manufacturers into a unified control system viaprotocol conversion, reducing integration costs.

4.smart Buildings and Building Automation

The module connects HVAC units, lighting systems, and other devices,communicating with Building Management Systems (BMS) via theBACnet/lp protocol to achieve energy consumption optimization and fault (pre-wakning).

Product website:

https://www.3splc.com/MVI56E-MNETC_c0_ss

The RroSoft MVlS6E-MNETCR module has emerged as a critical componentfor connecting heterogeneous networks in industrial automation, thanks to its protocol conversion capabilities, high-reliability design, and flexibledeployment. whether upgrading traditional factories or building new smartproduction lines, this module significantly reduces system integration costsand enhances data flow efficiency. For industrial users prioritizing efficiency,fexibility, and security, the MVIsGE-MNETCR is undoubtedlg a reliablechoice for constructing Industrial internet of Things (lloT) systems.
