Allen Bradley 2711-K3A10L1 Operator Interface Brand new

Allen Bradley 2711-K3A10L1 Operator Interface

The Allen-Bradley 2711-K3A10L1 is a Panelview 300 Standard Operator Terminal. This operator terminal is powered by an external 18-32V DC supply voltage and has a 3-inch display with embedded DeviceNet communication interface and RS232 Printer port. It has Eight (8) Function keys and a Keypad operator interface.

Technical specifications for 2711-K3A10L1

Backlight：100,000 hr LED backlight life

Brand：Allen-Bradley

Manufacturer：Rockwell Automation

Product Family：PanelView Standard Operator Terminals

Product Type：PanelView 300 Standard Operator Terminals

Display Type：Monochrome transflective LCD with LED backlight

Display Area：73 mm (w) x 42 mm (h) 2.87 in. (w) x 1.67 in. (h)

Resolution：128 x 64 Pixels

Keypad Assembly：8 function keys (F1…F8); Cursor keys; Numeric entry keys

Application memory：170 KB application runtime; 240 KB nonvolatile memory (application objects plus text and bitmaps)

Communication ports：DeviceNet; RS232 (Printer port)

Input Voltage range：18…32V DC (24V DC nom)

Enclosure：NEMA Type 12/13, 4X (Indoor use only), IP54, IP65

Status Indicators：COMM: Green Fault: Red

Part Number/Catalog No.：2711-K3A10L1

Product Line：Panelview 300

Display Size：3 in.

Display Color：Monochrome

Input Type：Keypad

Communication：DeviceNet Communication & RS-232 Port

Input Power：24 VDC

Memory：240 KB

Communication Cable：1761-CBL-PM02

Shipping Weight：3 lbs

Shipping Dimensions：11X8X6 in.

Series：A, B

Product Lifecycle Status*：Discontinued/Obsolete

Description:

The Allen-Bradley 2711-K3A10L1 is a PanelView 300 Terminal. The discontinued Allen-Bradley PanelView 300 2711-K3A10L1 is an operator terminal that enables the user to interface with their machine. The flat panel architecture of the 2711-K3A10L1 allows the user to maintain the high-level performance in a space-saving interface. Additionally, the display offers a variety of graphics on the monochrome display.

This Human-Machine Interface has a 3-inch monochrome display. This Panelview is configured using PanelBuilder 32 software, which runs on a personal computer. This terminal is equipped with DeviceNet communication and an RS-232 communication port with a 1761-CBL-PM02 communication cable.

The user is able to control the HMI using the Keypad to input information and data. The keypad has 8 function keys (F1 through F8). This unit is powered using 24 Volt DC and consumes up to 25 Watts when operating at 24 Volts DC. This unit has 240 kilobytes of internal memory. The internal backlight on this unit is non-replaceable.

The approximate shipping weight and dimensions are 3 pounds and 11 x 8 x 6 inches. The most common Series are A and B and the most common firmware include 4.00-4.48.

This unit comes with a gasket seal, in order to ensure a good seal make sure the sealing gasket is positioned correctly on the PanelView terminal. This gasket, when used correctly, is able to form a compression type seal. You should not use any sealing compounds on this unit.
