Allen Bradley 20BC205A3ANNANC0 PowerFlex 700 AC Drive 20B
Manufacturer : Rockwell Automation
Brand : Allen-Bradley
Part Number/Catalog No. : 20BC205A3ANNANC0
Degree of protection (IP) : IP20
Shock : 15 G peak for 11 ms duration (±1.0 ms)
PWM frequency 4 kHz @ 400V AC
Vibration : 0.152 mm (0.006 inch) displacement, 1 G peak
Number of analogue outputs : 2
Mains voltage : 400 V
Integrated breaking resistance : No
Brake IGBT : Without brake IGBT
Internal communication module : No communication module
Input voltage rating : 400V AC, 3-phase, 50 Hz
AC input undervoltage trip : 233V AC @ 380/400V
Bus voltage, nom : 540V DC @ 380/400V
Bus undervoltage shutoff/fault : 305V DC @ 380/400V
Bus overvoltage trip : 810V DC @ 380/400V
Output voltage rating : 0...400V AC @ 380...400V AC, 1-phase
Circuit breaker current rating, max : 600 A @ 400V AC, 3-phase, normal duty
Motor circuit protector current rating, max : 400 A @ 400V AC, 3-phase, normal duty
Output current rating, continuous : 205 A @ 400V AC, 3-phase, normal duty
Output current rating, 1 min : 255 A @ 400V AC, 3-phase, heavy duty
Output current rating, 3 sec : 313 A @ 400V AC, 3-phase, heavy duty
Logic control ride-thru : 0.5 seconds minimum, 2 seconds typical
Brake resistor : No internal brake resistor
Input current rating : 199 A @ 400V AC, 3-phase
Documentation : Manual
arrier frequency : 2, 4, 8, and 10 kHz. Drive rating based on 4 kHz
Encoder quadrature : 90 degrees, ±27 degrees at 25 °C (77 °F)
AC input overvoltage trip : 570V AC @ 380/400V
Input power rating : 148 kVA @ 400V AC, 3-phase, normal duty
Dual element time delay fuse current rating : 250...450 A @ 400V AC, 3-phase, normal duty
Non-time delay fuse current rating : 250...600 A @ 400V AC, 3-phase, normal duty
Digital input latency, typical : 9.2 ms @ stop signal for SVC motor control
Heat sink thermistor : Monitored by microprocessor overtemp trip
Digital input latency : 9.2...16.0 ms @ start signal for SVC motor control
Drive to motor power ratio, max : Recommended not greater than 2:1 ratio
