Allen Bradley 1756-OF8 ControlLogix 8 Pt A/O I or V Module Brand new

Allen Bradley 1756-OF8 ControlLogix 8 Pt A/O I or V Module

The Allen-Bradley 1756-OF8 is an analog output module from the ControlLogix product family. This module features Eight (8) output channels, configurable for +/-10VDC Voltage and 0-20 mA Current output signals with resolution of 15 bits across 21 mA - 650 nA/bit and 15 bits across 10.4V - 320 µV/bit. It may be used as a local or distributed I/O module.

Technical specifications for 1756-OF8

Manufacturer：Rockwell Automation

Enclosure：None

Module Type：Analog Output Module

Series：ControlLogix

Part Number/Catalog No.：1756-OF8

Brand：Allen-Bradley

No. of Outputs：Eight (8) Current / Voltage

Output Current Range：0-20 mA

Output Voltage Range：+/- 10VDC

Resolution：15bit

Data Format：Integer mode (left justified, 2 s complement) IEEE 32-bit floating point

Conversion Method：R-Ladder DAC, monotonicity with no missing codes

Open circuit detection：Current only

Short circuit detection：Electronically current limited to 21 mA or less

Overvoltage protection：24V DC

Outputs：8 Current-Voltage

Backplane Current (5Volts)：140 milliamps

Backplane Current (24 Volts)：210 milliamps

Removable Terminal Blocks：1756-TBNH, 1756-TBSH

Power Dissipation (Max)：4.9 Watts at 60 Celsius

Removeable Terminal Block(s)：1756-TBNH, 1756-TBSH

Isolation Voltage：50 Volts Continuous

Description:

The Allen-Bradley 1756-OF8 is an analog output module that is part of the ControlLogix platform. This analog module may be used to control and modulate electrical and field devices, transmit or re-transmits signals for interfacing with measuring and recording instruments or for any other purpose.

The 1756-OF8 comes with Eight (8) analog output channels configurable for +/-10VDC and 0-20 mA analog output signals. It has a resolution of 15 bits across 21 mA - 650 nA/bit and 15 bits across 10.4V - 320 µV/bit with open circuit, short circuit and overvoltage protection capability.

The 1756-OF8 uses R-Ladder DAC, monotonicity with no missing codes module conversion method and provides register data in the form of Integer mode (left justified, 2 s complement) IEEE 32-bit floating point. It has a scan time of 12 ms for floating point format and 8 ms for integer format.
