Allen Bradley 1756-DHRIO ControlLogix DH Plus/RIO Comms Module
The 1756-DHRIO is an Allen-Bradley communication module that support Remote I/O and Data Highway Plus (DH) protocol. This module has embedded Two (2) ports for Channel A and B each with a with 3-Pin terminal for wiring Data Highway Plus (DH+) or Remote I/O (RIO) and a single 8-Pin mini-DIN port that is connected parallel to Channel A.It supports the following types of communication: Remote I/O, Control and Information Protocol (CIP) Messaging, and Data Highway Plus (DH+) Messaging between devices. It can have up to 32 Logix connections and the remote I/O link can connect to a remote I/O device, as well as other intelligent devices. When connected to a remote I/O network, it can act as an adapter or scanner and transfer analog, digital, block, and specialty data even with the absence of message instructions. Prior to installing the 1756-DHRIO module, you need to program the network type switches for each channel and install and connect a ControlLogix power supply and chassis. You can install as many modules as you can in the same chassis but this will depend on your available power supply.Note that modules can also be installed or removed even when the chassis power is applied but you need to observe safety precautions, particularly that the area is nonhazardous and power is removed, to prevent an electrical arc that can cause excessive wear to the contacts of both the module and the connector. Make sure to discharge potential static because the module is sensitive to electrostatic discharge.
Technical specifications for 1756-DHRIO
Manufacturer:Rockwell Automation
Brand:Allen-Bradley
Part Number/Catalog No.:1756-DHRIO
Series:ControlLogix
Module Type:Data Highway/Remote I-O Communication Module
Location:1756 ControlLogix Chassis
Communication Speed:57.6 Kbaud, 115.2 Kbaud, 230.4 Kbaud
Cable Length:3048 m (10000 ft), , 1524 m (5000 ft),762 m (2500 ft)
Recommended Cable:Belden 89463 twinaxial, 0.52 mm² (20 AWG)rated at 200 °C (392 °F)
Backplane Current (5Volts):1.7 milliamps
Backplane Current (24 Volts):850 milliamps
Power Dissipation (Max):4.5 Watts
Thermal Dissipation (Max):15.4 BTU per hour
Enclosure:Open
Operating Temperature:0-60 Celsius, 32-140 Fahrenheit
Slot width:1
Weight:0.64 pounds (0.293 kilograms)
Spare Connector kit:Phoenix MVSTBR2.5/3-ST BK AU.
