Allen Bradley 1756-A13 ControlLogix 13 Slots Chassis Brand new

Allen Bradley 1756-A13 ControlLogix 13 Slots Chassis

The Allen-Bradley 1756-A13 is ControlLogix chassis. This hardware provides Thirteen (13) module mounting slots, hosting the ControlLogix modules and enables backplane connectivity. This chassis has a maximum backplane current of 1.5 A @ 1.2VDC; 4A/4A @ 3.3 VDC; 15 A/6 A @ 15 A/6 A and 2.8 A/2.8 A @ 24VDC. It supports horizontal mounting with minimum cabinet size requirement of 60.9 x 76.2 x 20.3 cm (24 x 30 x 8 in.).

Technical specifications for 1756-A13

Manufacturer：Rockwell Automation

Mounting：Panel Mount

Module Type：Chassis

Series：ControlLogix

Part Number/Catalog No.：1756-A13

Brand：Allen-Bradley

No. of slots：Thirteen (13) slots

Backplane Current @ 1.2VDC：1.5 A

Backplane Current @ 3.3VDC：4A/4 A

Backplane Current @ 5.1VDC：15 A/6 A

Backplane Current @ 24VDC：2.8 A/2.8 A

Orientation：Horizontal

No. of mounting tabs：Eight (8)

Operating Temperature, Series B：0°C to +60°C (+32°F to +140°F)

Operating Temperature, Series C：-25…+60 °C (-13…+140 °F)

Storage Temperature：-40°C to +85°C (-40°F to +185°F)

Relative Humidity：5 to 95% (without condensation)

Wire size：Functional Earth Ground - 8.3 mm2 (8 AWG) solid or stranded copper wire rated at 90 °C (194 °F) or greater Protective Earth Ground - 2.1 mm2 (14 AWG) solid or stranded copper wire rated at 90 °C (194 °F) or greater

Slots：13

Power Dissipation (Max)：5.4 Watts

Dimensions：24 x 30 x 8 inches

Weight：4.2 pounds (1.9 kilograms)

Enclosure：Open

Backplane Current (5 Volts DC)：10 amps

Backplane Current (24 Volts DC)：2.8 Amps

Description:

The 1756-A13 is a ControlLogix chassis from Allen-Bradley. This chassis provides module housing, providing 13 module slots where ControlLogix controllers and I/O modules may be installed. Aside from providing the mounting slots, the chassis also host the electronic circuitry which make-up the backplane. The backplane distributes the current which is used by each of the module to energize individual circuitry to function properly.

The 1756-A13 supports horizontal mounting only. It requires minimum cabinet size of 60.9 x 76.2 x 20.3 cm (24 x 30 x 8 in.) for installation and weighs 1.90 kg (4.2 lb). It is directly installed to the enclosure subpanel via the provided mounting tabs located on top and bottom of the chassis. Install this chassis at a temperature range of 0…60 °C (32…140 °F) for Series A and B chassis and -25…+60 °C (-13…+140 °F) for Series C chassis. It has operating vibration rating of 2 g @ 10…500 Hz and operating shock rating of 30 g. This chassis may be used with the Logix 5560, 5570 and 5580 product families.

The 1756-A13 has backplane current consumption of 1.5 A @ 1.2VDC; 4A/4A @ 3.3 VDC; 15 A/6 A @ 15 A/6 A and 2.8 A/2.8 A @ 24VDC. It has power dissipation of 5.4 Watts with an open type enclosure rating.
