Allen Bradley 1746-INT4 SLC 500 Isolated Thermocouple/mV Analog Input Module
Description For1746-INT4
It provides isolation tested at 1000V transient or 150V AC between channel-to-channel and channel-to-backplane. It has 5 LED indicators with 4 indicating each channel status and one indicating the module’s status. It has selectable B, C, D, E, J, K, N, R, S, and T thermocouple input types, and 50-50 mV DC and 100-100 mV DC analog inputs. It has an input impedance greater than 10 Mega Ohms and offers a 20nA open-circuit detection, with a circuit detection time of 5ms. It has a step response time of 600ms in the worst circuit case, and the module has an overall accuracy that is input-type dependent. Its operating temperature ranges from 0-60 deg. Celsius (32-140 deg. Fahrenheit) at 5-95% non-condensing humidity and is CE, CSA, and UL-certified.
The Allen-Bradley 1746-INT4 is a Four (4) channel Thermocouple / mV analog input module. This module is used for SLC 500 Programmable Logic Controller (PLC) platform. This module is compatible with Thermocouple sensors Type C, D, J, K, T, E, R, S, B, and N. It may also be used with mV signal with range of -100 to 100 mV DC.
This module may be used in applications with Temperature range of -270 to 1820 Deg. Celsius. Each Thermocouple has specific different range that is within the absolute range. Additionally, operable mV signal voltage are -50 to 50 mV and -100 to 100 mV which typically comes from signal transducers. This module follows Thermocouple linearization of IPTS–68 standard, NBS MN–125 and NBS MN–161. It also has Cold Junction Compensation terminal that enables accuracy of Accuracy ±1.5 °C (34.7 °F), 0 … 70 °C (32…158 °F). It has a user selectable Temperature scale of °C or °F and 0.1 °C or 0.1 °F and millivolt scale of 0.1 mV or 0.01 mV.
Allen Bradley's 1768-PB3 is a CompactLogix power supply. The 1768-PB3 is powered through the CompactLogix backplane. By using this backplane, the 1768-PB3 power supply is compatible with the 1768 and 1769 controllers, input/output modules, and power supply
Product specification
Model Number: 1746-INT4
Product name: 1746-INT4
Payment :Paypal\TT\Western Union\ Trade Assurance
MOQ :1PCS
Package :Carton Package
Shipping By DHL\UPS\Fedex\EMS\TNT\Aramex
Service :24 Hours Online Service
Lead time :5-7 Days
Condition :100% Original
Original factory:Allen-Bradley1746-INT4 In stock best price
| Shipping term: TNT DHL FEDEX UPS |
| Warranty: 12 Months |
| Condition: Original & new |
